型号: | 6mm-15mm |
---|---|
品牌: | 同丰软管 |
原产地: | 中国 |
类别: | 建筑、装饰 / 建筑用管和附件 / 管件 |
标签︰ | 特种软管 , 金属软管 , 不锈钢软管 |
单价: |
¥20
/ 米
|
最少订量: | 500 米 |
Size(单扣) | Inside Diameter | Outside Diameter | Coiling Diameter | Weight | Breaking Load Min |
4mm | 4.0mm | 6.0mm | 46mm | 0.045 Kg/m | 66 Kg |
5mm | 4.8mm | 6.8mm | 46mm | 0.049 Kg/m | 68 Kg |
5.5mm | 5.6mm | 7.7mm | 46mm | 0.059 Kg/m | 70 Kg |
6mm | 6.4mm | 8.4mm | 51mm | 0.061 Kg/m | 86 Kg |
7mm | 7.2mm | 9.5mm | 51mm | 0.072 Kg/m | 91 Kg |
8mm | 8.0mm | 10.9mm | 51mm | 0.082 Kg/m | 91 Kg |
9.5mm | 9.5mm | 12.7mm | 51mm | 0.131 Kg/m | 102 Kg |
12.7mm | 12.7mm | 15.9mm | 64mm | 0.157 Kg/m | 113 Kg |
Size(双扣) | Inside Diameter | Outside Diameter | Coiling Diameter | Weight | Breaking Load Min |
5mm | 4.8mm | 6.8mm | 51mm | 0.060 Kg/m | 86 Kg |
5.5mm | 5.5mm | 7.7mm | 51mm | 0.067 Kg/m | 91 Kg |
6mm | 6.4mm | 8.4mm | 51mm | 0.068 Kg/m | 113 Kg |
7mm | 7mm | 9mm | 51mm | 0.069 Kg/m | 140 Kg |
慈溪市横河镇同丰金属软管厂 | |
---|---|
国家/地区︰ | 浙江省宁波市 |
经营性质︰ | 生产商 |
联系电话︰ | 13805810599 |
联系人︰ | 杨一辉 (总经理) |
最后上线︰ | 2023/12/06 |
