| Cabin System |
Wallboard |
EPS (epispastics polystyrene) 50mm Thick, Colorful Steel Skin Boards 0.426mm Thick, Galvanized Steel Roof Panel, Tongue & Groove Style, Compound Construction, Anti-flame and Heat-Insulation |
| Basement |
Galvanized Steel Sheet and Square Steel Pipe assembling, Whole Grid with floor filter, Whole Ramps |
| Air Circulation System |
Inlet Fan |
Volume: 12000m3/h |
Power: 4kw |
Quantity: 2 sets |
| Outlet Fan |
Volume: 10000m3/h |
Power: 5.5kw |
Quantity: 1 sets |
| 60 units Ceiling Nozzles with 3 sets Centrifugal Fans for Drying Water Paint, 2 sets dryer inside the booth, Air Volume: 30000m 3 /h; Air Speed: 0.3-0.5m/s |
| Air Purification System |
Dual Filtering Structure, The Primary Filter Can Capture Granules Larger than 10 μm. Ceiling Filter Capture Granules Bigger than 5μm. The Whole Purification System Has Capacity of Large Volume of Dust. It’s Filtering Rate Reaches 98%. |
| Heating System |
Burner |
Italy Riello Brand, RG5S Diesel Burner, 260000Kcal/h, The Heating Time 4-5min |
| Heat Energy Converter |
Stainless Steel, Argon Arc Welding. The Heat Exchange Rate 85% |
| Max Temp:80ºC, Fuel Consumption: 4-5kg/vehicle, BELIMO Electric Damp |
| Light System |
Ceiling Light: 24 pcs 40w Lamp; Side light: 16 pcs 40w Lamp; 800 Lux |
| Other |
Spare parts holding bar at the rear |
