Product Description
Besides SAW touch screen for system operation using,there is another screen for advertizing or information display.
Response time: less than 16 ms
Material :standard pure glass with 3mm thickness or heat tempered glass with thick of 6mm(optional)
Enclosure:Durable steel enclosure,Quality lock or door for different parts on the cabinet.

Touch screen features:
Optional size15" 17" 19" 20"
Touch screen:SAW or infared touchscreen or resistive touchscreen.

Surface Acoustic Wave touchscreen
* Resolution: 4096×4096,Z axis256 grade
* Material :pure tempered glass
*Brightness: 300cd/
*lens transmission : 90% 92%
*Orientation precision: < 2mm0.080 inch
*Single-point touch Life expectancy : more than 50,000,000 times
*Surface hardness: equivalent to glass,7 Mohs
*Dust-proof ,explosive proof
*Darability:5years

Grade A LCD monitor:
Brand:LG or SAMSUNG
Size: 15' ,17.1'',19'',22'' etc
Aspect ratio: 4:3,
Max resolution:1280x1024 for 15,17inch screen.,Brightness: 260cd/m2 ,Contrast: 450:1
Size and Brand are optional


Powerful PC:
Intel Core 2 Duo E2180 2.0G CPU/ DDRII 1G EMS memory /160G HD / Intel G31 mainboard/(sound driver/display card driver /10-100M netcard driver)
Multi-media system:amplifier; stereo Loudspeaker; magnetic-proof,net card, sound card,integrated display card,
Operation system: Windows2000/XP/Vista, RedHatLinux/FedoraCore
Power supply : AC110V-240V ,50H-60HZ
Network connector RJ45 connector and inner network connection, wireless network card

Optinal accessories:
*Barcode reader, Non-contact IC/ID card reader,Credit card reader.
*Coin/Bill acceptor.
*16bit/64bit Metal Keyboard, stainless steel keyboardwith trackball.
*Camera,Thermal /Laser printer, buletooth connection, etc.

Color: we can paint your own color,free of charge
Cabinet: Steel cabinet sprayed metallic paint or plastic-spray,2.0MM steel,moisture-proof,anti-rust,anti-acid,anti-dust
Packing:foam ,carton,wooden case
Dimension: 1.40-1.60m different from the models (customized)
Working environment: temperature +0-+40, relative humidity 10%-90%
Control System: Integrated Circuit Controller
Basic Software: Touchscreen Driver system
Warranty: One year.

We can customize your own designs.,print your own logo on the kiosk .
Please feel free to contact us for more information.
