Specification(规格):

ELECTRICAL(电气特性):
(接触电阻)INITIAL CONTACT RESISTANCE:30mΩ Max.
(操作力量)OPERATION FORCE:500±200gf
(绝缘电阻)INSULATION RESISTANCE:100MΩ Min. 500VDC
(电气寿命)ENDURANCE:10,000 CYCLES
(耐 电 压)WITHSTAND VOLTAGE:1 KVAC FOR 1MINUTE

MATERIAL(材质)：
TERMINAL ENCLOSUER:PHENOLIC(UL 94V-0)
ACTUATOR:PBT+30%G.F.(UL 94V-0)
CONTACT:Ag Alloy
SPRING:STAINLESS STEEL WIRE
