HR10/HR10A 日本广濑圆形推拉自锁连接器

HR10/HR10A 日本广濑圆形推拉自锁连接器
型号:HR10A/HR10
品牌:AODU
原产地:中国
类别:电子、电力 / 电子元器件 / 端子、连接器
标签︰HR10A , HRS , 圆形连接器
单价: ¥105 / 件
最少订量:20 件

产品描述

1J系列连接器能够供应2芯、3芯、4芯、5芯、6芯、7芯 6种规格产品。
2J系列对接/面板连接器,含有7芯、10芯、12芯三种规格。
3J系列的面板安装连接器有4芯 6芯 两种规格

方便快捷的推拉自锁功能,广泛应用于各种设备。

应用于包括航空、航海、计算机、仪器仪表,CCD工业照相机等设备。

欢迎广大客户前来咨询订购,单只也可购买。

联系人:李先生

QQ:2458132363

主要用于计算机及外围设备、医疗设备、音频、视频、无线电、测量设备等



HRS|HRS广濑连接器|HRS接线端子HR10A-7P-12PA

本公司专业代理HRS|HRS连接器|日本广濑连接器|HRS接线端子常用型号备有库存,特价销售,交期短
HR10A-7P-4S HR10A-7P-4P HR10A-7J-4S HR10A-7J-4P HR10A-7R-4S HR10A-7R-4P HR10A-7R-4SB HR10A-7R-4PB HR10A-7P-6S HR10A-7P-6P HR10A-7J-6S HR10A-7J-6P HR10A-7R-6S HR10A-7R-6P HR10A-7R-6SB HR10A-7R-6PB HR10A-7P-7S HR10A-7P-7P HR10A-7J-7S HR10A-7J-7P HR10A-7R-7S HR10A-7R-7P HR10A-7R-7SB HR10A-7R-7PB HR10A-10P-7S HR10A-10P-7P HR10A-10J-7S HR10A-10J-7P HR10A-10R-7S HR10A-10R-7P HR10A-10R-7SB HR10A-10R-7PB HR10A-10P-10S HR10A-10P-10P HR10A-10LP-10S HR10A-10LP-10P HR10A-10J-10S HR10A-10J-10P HR10A-10R-10S HR10A-10R-10P HR10A-10R-10SB HR10A-10R-10PB HR10A-10P-12S HR10A-10P-12P HR10A-10LP-12S HR10A-10LP-12P HR10A-10J-12S HR10A-10J-12P HR10A-10R-12S HR10A-10R-12P HR10A-10R-12SB HR10A-10R-12PB HR25-9TP-16S HR25-9TP-16P HR25-9TJ-16S HR25-9PJ-16P





Characteristic
 Specifications

No. of Positions
 7, 10, 12

Current Rating(Amps)(Max.)
 2

Shell Size (dia)
 7, 10, 13

PCB Mount Type
 Through-hole

Contact Mating Area Plating
 Tin, Gold, Silver

Operating Temperature Range (degrees C)
 -25, -10 to 60, 85

Applicable Cable
 0.8D-QEW.CW, Cable outer dia.Φ3, Solder cup inside dia.Φ0.8, Conductor AWG#26 max., Cable outer dia.Φ5, Conductor AWG#26 to #30, Cable outer dia.Φ5, Solder cup inside dia.Φ0.8, Conductor AWG#26 max., Cable outer dia.Φ6, Conductor AWG#26 to #30, Cable outer dia.Φ6, Solder cup inside dia.Φ0.8, Conductor AWG#26 max., Cable outer dia.Φ6.2, Solder cup inside dia.Φ0.8, Conductor AWG#26 max., Cable outer dia.Φ6.4, Solder cup inside dia.Φ0.8, Conductor AWG#26 max., Cable outer dia.Φ7, Conductor AWG#26 to #30, Cable outer dia.Φ7, Solder cup inside dia.Φ0.8, Conductor AWG#26 max., Cable outer dia.Φ8.3, Solder cup inside dia.Φ0.8, Conductor AWG#26 max., Cable outer dia.Φ9, Solder cup inside dia.Φ0.8, Conductor AWG#26 max., Cable outer dia.Φ9.5, Conductor AWG#26 to #30, Conductor AWG#26 to #30, Solder cup inside dia.Φ0.8, Conductor AWG#26 max.

Termination Style
 Crimping, Soldering

Connector Type
 Board mounting/Cable/Panel/Wire

Contact Gender
 Female, Male

Mating/Unmating Cycles
 1000

Remarks
 Connection tools, Automatic crimp machine, Crimp tool, Extraction tool


付款方式︰TT
