| Item |
Description |
Parameter |
| 1 |
X, Y, Z working area |
2000x4000x200mm |
| 2 |
Table size |
2165X4500mm |
| 3 |
Resolution |
±0.03/300mm |
| 4 |
Repeatability |
±0.05mm |
| 5 |
Lathe sructure |
Steel tube frame |
| 6 |
X structure |
Rack pinion, linear rails |
| 7 |
Y structure |
Rack pinion, linear rails |
| 8 |
Z structure |
Ball screw, linear rails |
| 9 |
Max. consume power |
6.5KW |
| 10 |
Max. rapid |
0-32000mm/min |
| 11 |
Max. working speed |
0-20000mm/min |
| 12 |
Spindle power motor |
3Kw italian HSD Spindle, ER25 |
| 13 |
Spindle speed |
0-18000RPM |
| 14 |
Working mode |
Stepper |
| 15 |
Working voltage |
3 phase AC380V/50HZ/60Hz |
| 16 |
Command code |
G code(*uoo,*nc,*mmg, *plt) |
| 17 |
Operating system |
DSP System |
| 18 |
Interface |
Printer port 50pins or USB |
| 19 |
System memory |
128M (or pen driver) |
| 20 |
Collet |
ER25 |
| 21 |
X, Y working delicacy |
<0.01mm |
| 22 |
Software |
Type3 software, ucancam software, copy artcam software |
| 23 |
Running circumstance |
Temperature: 0℃～45℃ |
| relative humidity: 30%～75% |
| 24 |
Packing size |
4680x2200x1750mm |
| 25 |
Net weight |
1950KG |
| 26 |
Gross weight |
2300KG |
| option |
Vacuum table |
T slot vacuum table |
| Vacuum pump |
germany becker 4kw 140cbm/h |
| dust extractor |
3kw double bags |
