日本SHIMADZU島津SGP1A齒輪泵

日本SHIMADZU島津SGP1A齒輪泵
型號:SGP1A,SGP2A
品牌:SHIMADZU
原產地:日本
類別:工業設備 / 通用機械 / 泵及真空設備
標籤︰SHIMADZU齒輪泵 , SGP1齒輪泵 , SGP2齒輪泵
單價: -
最少訂量:1 件

產品描述

日本島津SHIMADZU SGP1,SGP2  PUMPS / 崑山甦美自動化科技有限公司專業供應.
SGP1,SGP2 series
SGP1 and SGP2 series high pressure gear pumps are an advanced version of conventional gear pumps using specialized cast iron body. They can withstand any adverse conditions of surge pressure, wide temperature and wide speed range with long life. Especially they maintains high performance during high temperature and low speed operation. Ceramic coating in SGP2 pump realizes invented step in sealing device for leakage loss


型 號 理論排量 mL/r 額定壓力MPa 最高壓力 MPa 最高轉速 r/min 最低轉速 r/min
SGP1-16 15.9 20.5 24.53 4000 400
SGP1-18 17.9
SGP1-20 20.0
SGP1-23 23.3
SGP1-25 24.5 3500
SGP1-27 27.3 3500
SGP1-28.2 28.2 3000
SGP1-30 29.2
SGP1-30.8 30.4
SGP1-31.9 31.5
SGP1-32 32.4
SGP1-34 33.2
SGP1-36
35.7

型號 最高壓力 額定壓力 排量 配管尺寸 容許轉數rpm 重量(kg
(MPa) MPa m/rev 入口 出口
      L F L F 最低 最高
SGP1A16 24.5 20.6 16.2 Ø25 PT1" Ø19 PT3/4" 500 4000 3.3
SGP1A18 24.5 20.6 18.3 Ø25 PT1" Ø19 PT3/4" 500 4000 3.4
SGP1A20 24.5 20.6 20,4 Ø25 PT1" Ø19 PT3/4" 500 4000 3.5
SGP1A23 24.5 20.6 23.7 Ø25 PT1" Ø19 PT3/4" 400 4000 3.7
SGP1A25 24.5 20.6 24.9 Ø25 PT1" Ø19 PT3/4" 400 3500 4
SGP1A27 24.5 20.6 27.8 Ø25 PT1" Ø19 PT3/4" 400 3500 4
SGP1A30 24.5 20.6 29.9 Ø25 PT1" Ø19 PT3/4" 400 3000 4.1
SGP1A32 24.5 20.6 33.2 Ø25 PT1" Ø19 PT3/4" 400 3000 4.2
SGP1A34 20.6 18.6 34.1 Ø25 PT1" Ø19 PT3/4" 400 3000 4.3
SGP1A36 20.6 17.2 36.6 Ø25 PT1" Ø19 PT3/4" 400 3000
4.5

日本SHIMADZU島津SGP1部分型號:
SGP1A16F1H1AR,SGP1A16F1H2-L,SGP1A16F1H2-R,SGP1A16F1H5-L,
SGP1A16F1H5-R,SGP1A16F2H1AL,SGP1A16F2H1AR,SGP1A16F2H2-L,
SGP1A16F2H2-R,SGP1A16F2H5-L,SGP1A16F2H5-R,SGP1A16D1H1AL,
SGP1A16D1H1AR,SGP1A16D1H2-L,SGP1A16D1H2-R,SGP1A16D1H5-L,
SGP1A16D1H5-R,SGP1A16D2H1AL,SGP1A16D2H1AR,SGP1A16D2H2-L,
SGP1A16D2H2-R,SGP1A16D2H5-L,SGP1A16D2H5-R,SGP1-18F1H1-L,
SGP1-18F1H1-R,SGP1-18F1H2-L,SGP1-18F1H2-R,SGP1-18F1H5-L,
SGP1-18F1H5-R,SGP1-18F2H1-L,SGP1-18F2H1-R,SGP1-18F2H2-L,
SGP1-18F2H2-R,SGP1-18F2H5-L,SGP1-18F2H5-R,SGP1-18D1H1-L,
SGP1-18D1H1-R,SGP1-18D1H2-L,SGP1-18D1H2-R,SGP1-18D1H5-L,
SGP1-18D1H5-R,SGP1-18D2H1-L,SGP1-18D2H1-R,SGP1-18D2H2-L,
SGP1-18D2H2-R,SGP1-18D2H5-L,SGP1-18D2H5-R,SGP1A18F1H1AL,
SGP1A18F1H1AR,SGP1A18F1H2-L,SGP1A18F1H2-R,SGP1A18F1H5-L,
SGP1A18F1H5-R,SGP1A18F2H1AL,SGP1A18F2H1AR,SGP1A18F2H2-L,SGP1A18F2H2-R,SGP1A18F2H5-L,SGP1A18F2H5-R,SGP1A18D1H1AL,SGP1A18D1H1AR,SGP1A18D1H2-L,SGP1A18D1H2-R,SGP1A18D1H5-L,SGP1A18D1H5-R,SGP1A18D2H1AL,SGP1A18D2H1AR,SGP1A18D2H2-L,SGP1A18D2H2-R,SGP1A18D2H5-L,SGP1A18D2H5-R,SGP1-20F1H1-L,SGP1-20F1H1-R,GP1-20F1H2-L,SGP1-20F1H2-R,SGP1-20F1H5-L,SGP1-20F1H5-R,SGP1-20F2H1-L,SGP1-20F2H1-R,SGP1-20F2H2-L,SGP1-20F2H2-R,SGP1-20F2H5-L,SGP1-20F2H5-R,SGP1-20D1H1-L,SGP1-20D1H1-R,SGP1-20D1H2-L,SGP1-20D1H2-R,SGP1-20D1H5-L,SGP1-20D1H5-R,SGP1-20D2H1-L,SGP1-20D2H1-R,SGP1-20D2H2-L,SGP1-20D2H2-R,SGP1-20D2H5-L,SGP1-20D2H5-R,SGP1A20F1H1AL,SGP1A20F1H1AR,SGP1A20F1H2-L,SGP1A20F1H2-R,SGP1A20F1H5-L,SGP1A20F1H5-R,SGP1A20F2H1AL,SGP1A20F2H1AR,SGP1A20F2H2-L,SGP1A20F2H2-R,SGP1A20F2H5-L,SGP1A20F2H5-R,SGP1A20D1H1AL,
SGP1A20D1H1AR,SGP1A20D1H2-L,SGP1A20D1H2-R,SGP1A20D1H5-L,SGP1A20D1H5-R,SGP1A20D2H1AL,SGP1A20D2H1AR,SGP1A20D2H2-L,SGP1A20D2H2-R,SGP1A20D2H5-L,SGP1A20D2H5-R,SGP1-23F1H1-L,SGP1-23F1H1-R,SGP1-23F1H2-L,SGP1-23F1H2-R,
SGP1-23F1H5-L,SGP1-23F1H5-R,SGP1-23F2H1-L,SGP1-23F2H1-R,
SGP1-23F2H2-L,
SGP1-23F2H2-R,SGP1-23F2H5-L,SGP1-23F2H5-R,
SGP1-23D1H1-L,SGP1-23D1H1-R,GP1-23D1H2-L,SGP1-23D1H2-R,
SGP1-23D1H5-L,SGP1-23D1H5-R,SGP1-23D2H1-L,SGP1-23D2H1-R,
SGP1-23D2H2-L,SGP1-23D2H2-R,
日本SHIMADZU島津SGP1A齒輪泵 1日本SHIMADZU島津SGP1A齒輪泵 2日本SHIMADZU島津SGP1A齒輪泵 3日本SHIMADZU島津SGP1A齒輪泵 4
