電氣參數 ELECTRICAL SPECIFICATIONS

頻率範圍                   150~160 MHz

Frequency Range

輸入阻抗                   50Ω

Impedance

駐波比                     ＜1.5(155 MHz)

VSWR

增益                       3 dBi

Gain

極化方式                        垂直 Vertical

Polarization

輻射方向                        全向 Omni

Radiation

避雷保護                        直流接地

Lighting Protection                Direct Ground

功率容量                        120 W

Maximum Power Input-watts

機械特性 MECHANICAL SPECIFICATIONS

高度                       730 ± 3 mm

Height

接頭                       NMO

Termination

底部直徑                        Ø39.4±0.2 mm

Diameter of Chassis

輻射振子材料                    不鏽鋼 Stainless Steel

Radiating Element Material
