| Specification |
2.3m Carriage |
2.6m Carriage |
2.3m Container |
2.5m Container |
| Vehicle Parameters |
|
| L*W*H (Overall Dimension) mm |
3660ｘ1420ｘ1760 |
3960ｘ1420ｘ1760 |
3660ｘ1420ｘ1960 |
3860ｘ1420ｘ1960 |
L*W*H
(Carriage/Container Dimension) mm |
2300ｘ1420ｘ400 |
2600ｘ1420ｘ400 |
2300ｘ1420ｘ1300 |
2500ｘ1420ｘ1300 |
| Wheelbase mm |
2000 |
| Tread mm |
1260 |
Min. Ground Clearance
(Full loaded/ Half loaded)mm |
112/148 |
| Min. Turning Radius m |
≤5 |
| Curb Weight kg |
700 |
730 |
760 |
780 |
| Tire Specification |
145/70R12 |
| Max. Speed km/h |
45 |
| Max. Gradability % |
20-30 |
| Electric Comsumption of Hundred Kilometer kwh |
10 |
| Transmission Form |
Stepless speed change |
| Electric Motor |
|
| Model |
Brushless DC Electric Motor/Communication AC Electric Motor |
| Rated Voltage v |
72 |
| Rated KW kw |
2.5-4 |
| Rated Turning Speed RPM |
3850-4500 |
| Braking suspension driving mode |
|
| Braking System |
Disc brake/Drum brake |
| Suspension System |
Front: Mcpherson Independent Suspension Back: Steel suspension |
| Driving Model |
Rear Drive |
| Battery (lead acid battery) |
|
| Rated capacity Ah |
120-150 |
| Rated Voltage v |
72 |
| Charger |
|
| Input Voltage |
220v(Communication) |
| Charging Time |
8-10 hours |
| Endurance Mileage KM |
100-150 |
