Inputs - 2

Outputs - 4

Frequency Range (MHz) - 88 te 862

Typical Forward Gain (dB) - 7

Reverse Path Frequency Range (MHz) - 5 to 30

Typical Reverse Path Gain (dB) - 6

Max. Output (dBuV) - 89 Noise (dB) - <5

Connectors (Female on all Ports) - F

IR Control Capability -  Digital Link System

Power for Remote IR Receivers (via Outputs) - 9V DC at 15mA per Outlet

Short Curcuit Protection on Outputs - Yes

Power On LED Indicator - Blue

Supply (via Input) - 9V at 75mA Max

Mains Power Adapter Input - Yes (3.5mm Jack)

Screened - Yes

Operating Temperature Range -10°C te +55°C

Plastic Housing (with clip on base) - Yes
