1) Inside Dimension: 6900×3900×2700mm(L×W×H)
2) Outside Dimension: 7000×5100×3400mm(L×W×H)
3) Main Door: 3-folds, 3000×2650mm(W×H)
4) Personal Door: 1-fold, 650×1800mm(W×H)
5) Wall Panels: 50mm thick EPS heat preservation wall panels, galvanized steel roof plates.
6) Basement and Floor: galvanized steel assemble, 300mm high, 2 rows of grilles and 3 rows of indented plates, 2 ramps, 700×1950mm(W×L).
7) Lighting: ceiling lights: 8units×3pcs=24pcs×36W; Side lights: optional.
8) Generator setting type: side upper inlet air, quadrate steel frame, coated steel.
9) Intake air system: 2×4KW double-intake centrifugal fans, air capacity is 24000m3/h.
10) Exhaust air system: optional.
11) Heating system: , heating productivity is 180000kcal/h, stainless steel heat exchanger, working temperature is 80℃, electric damper from spraying to baking cycle.
12) Filtering system: prefilter, high efficiency filter (ceiling filter), floor filter (fiberglass filter).
13) Control system: lighting switch, spraying, heat spraying, baking, time setting, temperature controller, failure indicator, temperature limit controller.
14) Total power: 36KW
