Parameters

Sensor

CMOS sensor, pixels: 640*480,30 frame per second

Illumination

White LED

Aimer

Red LED

Angle

40*30 degree

Default code

1D: Code 39, Code 128, UPC/EAN/JAN, Code 93, Interleaved 2 of 5, Codabar, Matrix 2 of 5, Industrial 25(Straight 2 of 5 Industrial)
2D: QR Code, Data Matrix, PDF417

Optional code

1D: China Post(Hong Kong 2 of 5), NEC 2 of 5, Code 11, MSI Plessey, GS1 Databar(RSS), Korea Post, Trioptic, GS1 Composite Code
2D:  MicroPDF417, Aztec Code, Codablock,  MaxiCode,  Chinese Sensible Code

Environment

Operating temperature

-20°C ~ +60°C

Storage temperature

-40°C ~ +85°C

Humidity

5% ~ 95% (non-condensing)
