船用浮球液位控制器

船用浮球液位控制器
型號:UQK-651/652-C
品牌:雙興儀表
原產地:中國
類別:工業設備 / 其他工業設備
標籤︰船用浮球液位開關 , 浮子開關 , 浮球液位控制器
單價: -
最少訂量:10 件
發送查詢

產品描述

UQK-651/652-C(B)型船用浮球液位控制器 MARINE FLOAT LEVEL CONTROLLER

概述 GENERAL

   UQK-651/652-C(B)型船用浮球液位控制器適用於船艦,化工及其它工業設備中對艙櫃內液位進行

兩位式控制和報警。

  UQK-651/652-C Type marine float level controller is  widely used in ship chemical industry and other industrial  instrument to control and alarm the level in tank by two position type .

朮參數 TECHNICAL SPECIFICATION

型    號 Model

UQK-651-C(B)

UQK-652-C(B)

安裝形式 Mounting type

側裝 Horizontal mounting

頂裝 Top mounting

開關結構 Switch type

SPDTAC:250V10A DC:125V0.6A 2xSPDT(可選Option

觸點容量 Contact capacity

AC220/10A  DC125V/1A

切換差   Switching error mm

20~70(mm)

10~40(mm)

介子比重 Medium gravity

≥0.85

介子溫度 Medium temp

≤120℃

工作壓力 Working pressure

1.0MPa

防護等級 Protection

IP66/IP68

防爆型式 Explosion proof type

ExdIIBT4    ExiaIICT5

法蘭標準 Flange standard

GB2506-89  GB573-65

浮球直徑 Float dia D mm

Φ60

Φ64

船用浮球液位控制器 1船用浮球液位控制器 2船用浮球液位控制器 3船用浮球液位控制器 4船用浮球液位控制器 5
