★採用進口直線方形導軌，高精度斜齒齒條，雙排四列滾珠滑塊，承重冗余大、運行平穩，精度高，壽命長。

Adoptsimported linear square rails,high-precision helical rack, doublerow and four column ball slider,heavy loading, stable operation,high precision,longlife.

★鋼架結構機身，剛性好，抖動少，長時間使用變形量少，使定位精度更加精確，機器承重力可達一噸以上，Y軸採用雙絲杠傳動，實現Y軸同步，消除阻力，避免龍門有扭曲現象，使得機器曲直線雕刻更加順暢。
Steelframe structure, good rigidity, low jitter, long timeuse of lessdeformation, so that more precise positioning accuracy,machinebearing up to a ton of above, the Y axis by double screwdrive,realize the Y axis synchronous, eliminating the resistance,toavoid Longmen distorted, making the machine more smoothlycurvedstraight lineengraving.

★恆功率5.5KW主軸電機，矢量型變頻器及恆功率，進口四軸承低噪音主軸，保証低轉速下扭鉅不變來確保刀得使用壽命和工作效率，切削力度大，效率高。

Constantpower 5.5KW spindle motor, converterand constant power, low noiseimport four bearing spindle, guaranteeunder low speed to ensurethat the knife was constant torsion majorservice life and workefficiency, cutting intensity,highefficiency.

★加滑動上料裝置，將重物放在滑輪上輕鬆推移。

Plussliding feeding device, the load on pulleyeasypassage.

★軟件兼容性好，可兼容Type3/Artcam/Castmate/文泰、精雕等多種CAD/CAM設計製作軟件

Goodcompatibility, can be compatible with Type3/ Artcam / Castmate /Wen Tai, carved and other CAD / CAMdesignsoftware.

★單向刀具冷卻系統，有效提高刀具使用壽命

Checktool cooling system, effectively improvetoollife.

★全部防塵防水設計，全方位保護機器傳動部件

Dustproofwaterproof design, all-roundprotection of machine transmissionparts.

★高硬度聚酯板平台耐用不變形

Highhardness of polyester plate platformdurable withoutdeformation.

★防塵、防靜電密封性電腦控制櫃

Dust,anti-static seal computercontrolcabinet.

 技術參數/Technicai-parameters



雕刻深度Carvin**epth

最大鵰刻深度300mm             Maximumdepth of300mm

雕刻速度Carvingspeed

最大鵰刻速度6000/分             Maximumspeed 6000 /min

總功率  Totalpower

7.5kw

防水功能

Waterprooffunction

三軸全進口防水材料              Threeaxle all imports of waterproofmaterial

主軸電機Spindlemotor

高速水冷電主軸                  Highspeed water cooledspindle

傳動部件Transmissionparts

XY軸：原裝進口小模數、高精度，直尺、斜齒齒條。Z軸：進口絲杆     TheXY axis: imported small modulus, high precision, ruler,helicalrack. The Z axis: importedscrew

直線導軌Linearguide

臺灣原裝進口矩形重載高精度四列滾珠直線導軌    Taiwanimports original rectangular heavy load and high precisionfourcolumn ball linear guiderail

管路    Pipeline

防老化水管油管                 Antiaging pipetubing

電氣線路Electricalcircuit

防老化壽命屏蔽電纜線            Antiaginglife shieldcable

冷卻    Cooling

循環水回流設計                  Circulatingwaterreturndesign

重量     Weight

1500kg

主軸轉速 Spindlespeed

24000轉/分                     24000rpm
