型號: | OEM |
---|---|
品牌: | OEM |
原產地: | 中國 |
類別: | 電子、電力 / 通信和廣播電視設備 / 廣播電視設備 |
標籤︰ | 有線數字機頂盒 , 歐洲機頂盒 , 杜比機頂盒 |
單價: |
US $15
/ 件
|
最少訂量: | 3000 件 |
廠家特價歐洲高清有線數字機頂盒DVB-C帶杜比Scart接口
Main System |
|
Main Processo |
Mstar MSD 7801 |
Memory |
Flash 32Mbit |
|
DDRII 512Mbit |
Demodulator |
|
Type |
DVB-C QAM |
Constellation |
16/32/64/128/256 QAM |
Symbol rate |
3.6~6.952Moaud |
Tuner & Channel |
|
Input connecto |
F-TYPE, 75 ohm |
Input Frequency |
54MHz ~ 862MHz |
Loop Through Output |
F-TYPE |
Video Decoder |
|
Transport Stream |
ISO/IEC 13818-2 MPEG-2 |
Profile Leve |
MPEG-2 MP@HL H.264 ISO/IEC 14496-10 |
Aspect Ratio |
4:3,16:9 |
Video Resolution |
480i/480p/576i/576p/720p/1080i/1080p |
Audio Decoder |
|
Audio Decoding |
MPEG-1 ,MPEG-2 (LayerI/ II) ,MP3 Audio |
Audio Sampling Frequency |
32,44.1,48KHZ |
Sound Mode |
Stereo,mono,dual |
A/V & Data In/Out |
|
HDMI |
HDMI 1.3 transmitter with HDCP |
RCA |
Transfer rate 115.2kps |
Power Supply |
|
Input Voltage |
110V—220 AC /5V-2A DC |
Power consumption |
8W(max) |
Mechanical |
|
Dimension |
195(W)×140(D)×42(H)mm |
包裝︰ | 40台/箱 |
---|---|
交貨期︰ | 25-30天 |
產品規格︰ | receiver size: 19.5*14.5*4cm 10pcs/ctn 0.0375CBM/CTN weight: 11kg/ctn |
產品優點︰ | 1.FULL HD 2. Cable tv receiver 3. Decode channels for Europe 4. Scart port 5. Support Dolby |
主要市場︰ | 歐洲 |
聯繫人:︰ | Annie: skype: annieli11111 |
深圳市邁越電子有限公司 | |
---|---|
國家/地區︰ | 广东省深圳市 |
經營性質︰ | 生產商 |
聯繫電話︰ | 13434777602 |
聯繫人︰ | Annie (市場經理) |
最後上線︰ | 2022/12/16 |
