桌面型網絡安全硬件平台。  F19401是一款桌面型網絡安全硬件平台，用於VPN、網絡帶寬管理、防火牆和其他嵌入式應用等。

Features
x86 desktop network appliance, small chassis size 300x210x44.5mm
Onboard Intel Bay Trial J1900 Quad-core Processor, 2.0GHz, L2 Cache
One 204-pin DDR3-L DIMM slots, up to 8 GB
Four Intel PCIe GbE controllers, Optional one channel bypass
One SATAinterface and one mSATA interface
Two USB3.0 interfaces
One RJ45 for RS232 communication
Optional one expansion wifi or 3G/4G module
Specifications
Motherboard
CPU Onboard Intel Bay Trial J1900 Quad-core CPU
System memory One 204-pin DDR3-L DIMM slots, up to 8GB
Storage
Interface One SATA and one mSATA connectors
Hard Drive One2.5" HDD tray
Ethernet
LAN Port Four 10/100/1000Mbps RJ-45 ports

Ethernet Controller Four Intel PCIe GbE controllers

BYPASS Optional one channels BYPASS

Wireless module Optional one expansion wifi or 3G/4G module(built-in a SIM slot)
Indicator Indicator RJ-45 with LAN link, active, speed LED, built-in BYPASS function LED
System I/O
USB Two USB3.0
COM One RJ-45 COM
Reset Button One built-in reset button
Indicator One Power LED, one HDD LED
Video Built-in one VGA interface, support hot plug(Internal)
Power supply
Power consumption Built-in 60W power supply
Power input 100 ~ 240V AC input
Environmental
Mounting Supports rack-mounting or desktop-mounting
Operate Temperature -10°C ~ 50°C
Storage Temperature -20°C ~ 75°C
Operate Humidity 5% ~ 85% non-condensing @ 40°C
Storage Humidity 5% ~ 95% non-condensing
Mechanical
Chassis Color Blue or OEM
Front panel Silver PVC (OEM/Neutral)
Construction Desktop chassis, Heavy duty metal
Dimensions (D x W x H) 300x210x44.5mm
Weight 5.8 kg
Ordering informations
F19401 Destop network appliance, J1900 CPU, 4 x GbE RJ45, 60W PSU
Optional NIC modules
83S5 4-ports 100M NIC module lan card supports mirror/switch mode
