非標陶瓷插芯陶瓷毛細管

型號：	round
品牌：	3V-TECH
原產地：	中國
類別：	電子、電力 / 通信和廣播電視設備 / 其他通訊產品
標籤︰	陶瓷插芯 , 非標插芯 , 陶瓷毛細管
單價：	¥1 / 件
最少訂量：	100 件

發送查詢

產品描述

3V TECHNOLOGY is a professional manufacturer with 18years experiences in producing optic fiber glass/ceramic capillary,round-shape ferrule,square-shape ferrule,D-shape ferrule or others.single-core type;dual-core type;multi-core type;cylindrical/rectangular shape optional;customized fiber glass capillary is supportable.

Features:

-Etching process for taper hole

-Good consistency of taper hole

-Good reliability and stable performance in harsh environment

-High chemical stability

-Machinable high-precision components

Application Field:

optical communications, sensing, lasing,medical devices and other industries.

Technical Parameters:

Material	Schott BF33(Borosilicate) or Ceramic(zirconia)
Shape	Round(cylindrical) Outer diameter:1.0mm,1.25mm,1.8mm,2.5mm or customize We support customized order.
Inner Diameter	0.082mm;0.125mm,0.230mm or customize We support customized order.
Length	3.5mm,6mm,6.5mm,7mm,10.5mm or customize
Entrance Hole	L1.5±1mm;W0.75±0.25mm or customize
