型號: | ADA |
---|---|
品牌: | ADA |
原產地: | 美國 |
類別: | 交通運輸 / 物流 / 起重裝卸設備 |
標籤︰ | ADA弔環 , Hoist Ring , 進口美製弔環 |
單價: |
¥200
/ 個
|
最少訂量: | 1 個 |
旋轉弔環、萬向旋轉弔環、起重旋轉弔環、合金鋼鍛造弔環、海用弔環、海油弔環、防腐弔環、煤礦弔環、模具弔環、進口弔環
The Rotating Hoist Ring UNC range has been expanded with three extra sizes from WLL 6.8t up to 13.6t.
The Rotating Hoist Ring UNC is a grade 8 rotating hoist ring with UNC thread. This hoist ring with UNC thread can
pivot 180擄 and rotate 360擄. It has UNC threads as standard. The cylindric head of the screw prevents jamming during rotation of the shackle.
The WLL indicated hereunder are given in the worst conditions of use, i.e. 90擄. It is necessary to check the free moving of the pivoting shackle. WLL and CE marking are mentioned on the product. The minimum safety factor is 5:1.
Rotating Hoist Ring UNC is available in a range with a working load limit from 0.4t up to 13.6t.
Additional information on the hoist rings are available on the tel
ADA Rotating Hoist Ring UNC, Grade 8 rotating ring
ADA Rotating Hoist Ring UNC GR8
Product code: ADAUNC
Material: alloy steel, Grade 8, quenched and tempered
Safety Factor: MBL equals 5 x WLL
Finish: painted white
Temperature range: -40擄C up to +200擄C (-40擄F up to +392擄F)
Certification:CE
Note: WLL indicated hereunder are given in the worst
conditions of use, i.e. 90擄
ADA Rotating Hoist Ring UNC, Grade 8 rotating hoist ring UNC, painted white, diameter thread 5/16", WLL 0.4 t
ADA Rotating Hoist Ring UNC, Grade 8 rotating hoist ring UNC, painted white, diameter thread 3/8", WLL 0.6 t
ADA Rotating Hoist Ring UNC, Grade 8 rotating hoist ring UNC, painted white, diameter thread 1/2", WLL 1 t
ADA Rotating Hoist Ring UNC, Grade 8 rotating hoist ring UNC, painted white, diameter thread 5/8", WLL 1.7t
ADA Rotating Hoist Ring UNC, Grade 8 rotating hoist ring UNC, painted white, diameter thread 3/4", WLL 2.5 t
ADA Rotating Hoist Ring UNC, Grade 8 rotating hoist ring UNC, painted white, diameter thread 7/8", WLL 3.5 t
ADA Rotating Hoist Ring UNC, Grade 8 rotating hoist ring UNC, painted white, diameter thread 1", WLL 4.5 t
ADA Rotating Hoist Ring UNC, Grade 8 rotating hoist ring UNC, painted white, diameter thread 1 1/4", WLL 6.8 t
ADA Rotating Hoist Ring UNC, Grade 8 rotating hoist ring UNC, painted white, diameter thread 1 1/2", WLL 10.8 t
ADA Rotating Hoist Ring UNC, Grade 8 rotating hoist ring UNC, painted white, diameter thread 2", WLL 13.6 t
