Parameter	Conditions	Minimum		Nominal	Maximum	Units
Linear Range	from null	-0.125			+0.125	in.
Linearity（ BSL）	over full range			±0.1	±0.25	%FS
Optimum Frequency		50		350	1100	Hz
Output（see Note 1）	at range limits	1.79		1.99	2.19	V
Primary impedance		247(+63)		275(+68)	303(+73)	ohms
Secondary impedance	entire secondary	997(+50.5)		1150(+56.5)	1323(+62.5)	ohms
Primary DCR		48.0		56.5	65.0	ohms
SECondary DCR	entire secondary					ohms
Phase Shift	primary to secondar	+1		+6	+11	deg
Null	see Note1				0.3	%FS
Output T.C.	see Note2			α =0.0*1m		(°C)¯¹
				ß =-6*1u		(°C)¯²
Note1：  Full Scale Output is twice the output at renge limit. Note2： V output at a temperature other then 25°C is:                               Vt=V25[1+α(∆t)+ ß(∆t)²]where∆t=t-25
Absolute Maximum Rations:
Voltage,windings to case:500 volts peak
Power Dissipation: 0.25Watt
Temperature,operating and storage:-35°C（-31°F）to + 80°C（+176°F）

High ensitivity;passive device
Precise repeatability
Infinite resolution
Environmentally r ed
Frictionless;hysteresis free

SPECIFICATIONS：
Electrical Performance Charaacteristics：
Measured at 25°C(77°F),using 5.0 volts RMS sine wave excitation at optimum requency--
