雙層輥筒熱銷型卷對卷輥筒印花機

型號：	BB42190
品牌：	高寶
原產地：	中國
類別：	工業設備 / 製版、印刷設備
標籤︰	輥筒印花機 , 輥筒轉印機 , 熱轉印機
單價：	¥79400 / 件
最少訂量：	1 件

發送查詢

產品描述

在卷布上面多色印花，最常見的就是輥筒轉印技術，先將需要轉印的圖案用噴墨打印機打印在具有塗層的昇華轉印紙上面，然後將昇華轉印紙覆蓋在卷布上面一起放入輥筒轉印機的工作臺上，輥筒印花機的主體結構是裝滿導熱油的可以旋轉的輥筒和緊緊壓在輥筒表面的毛毯構成。
熱昇華紙和卷布進入輥筒和毛毯之間，在熱和壓力的作用下，熱昇華紙上面的圖案會轉移到卷布表面，這就是市場上廣為流行的熱昇華轉印技術，它具有轉印色彩豐富，印刷效率高，環保，對皮膚損害低等優點，廣氾存在於服裝，鞋帽，床上用品，家居用品，窗帘等家庭用品行業。
輥筒印花機的主要參數是輥筒直徑和寬度，它決定了可以轉印的產品效率和寬度，對於輥筒直徑來說，直徑越大，效率越高，目前市場上1500mm的機器已經出現。寬度越大，轉印的布匹的寬度也越大，現在市場上可以做到3500mm寬度的機器。

BB42 Series Roller sublimation heat transfer machine Technical parameter
Model	BB42120	BB42170	BB42190
Roller Tape	Complex drum	Complex drum	Complex drum
Roller size	420*1200mm	420*1700mm	420*1900mm
Roller diameter	420mm	420mm	420mm
Roller surface	Coated with Teflon	Coated with Teflon	Coated with Teflon
Transfer width	1200mm	1700mm	1900
Transfer speed	120-380m/h	120-380m/h	120-380m/h
Diameter of shaft	50mm	50mm	50mm
Air swelling shaft	2	2	2
The main machine dim	190010001200	250010001200	26409001200
The work table dim	35001188900	35001888900	35002090900
Installed dim	450025001200	450025001200
Wooden box size	25801051330	25801051330
Net weight	520kg	600kg	750kg
Gross weight	550kg	650kg	800kg
Blanket size	17526808	17526808	195026808
Blanket separation method	Manual	Manual	Manual
Pressurized cylinder	1set	1set	1set
Air pressure	su80*50	su80*50	su80*50
Pressurized way	Pneumatic pressure	Pneumatic pressure	Pneumatic pressure
Pressure shaft diameter	87mm	87mm	87mm
Power supply	3 phase 380 volts	3 phase 380 volts	3 phase 380 volts
Current	41a/71a	41a/71a	40a
Heating tube and power	18*1.5=27kw	18*1.5=27kw	18*1.5=27kw
Heating method
Oil capacity	60kg	60kg	75kg
Heating temperature	260	260	260
Conveyor size	1680*7050	1680*7050	1950
Conveyor belt material	PVC	PVC	PVC
Glass size	1300940650 3Piece	1300940650 3Piece
Total glass size	2900*1710	2900*1710
BB42 Series Roller sublimation heat transfer machine advantage
Complex Roller Heating technical, Enquire heating more fast and stability Independent welding table, easy to install and remove; Air up the shaft roller, precise tension control, to ensure that the delivery of paper neat; Anti-pinch device to ensure safe operation; Microcomputer operation panel, simple and reliable; High burning point conveyor blankets, flame retardant performance; blanket thickness uniformity, the transfer effect is good; Teflon coating heating roller, effectively prevent electrostatic interference in the transfer process, roller temperature is small; Roller with internal and external precision turning and grinding, uniform thickness, heat transfer stability; Brand thermal oil, heat stable and uniform; Adjustable blanket roller rack pressure mechanism, pressure adjustment is simple and convenient; Independent pneumatic booster agencies to ensure high - pressure environment transfer, to achieve the transfer of color thousands; Brand electrical components, long life, low failure rate; latest collector ring signal transmission, high stability and long life; PVC conveyor belt, isolation paper reel, ribbon drive shaft speed can be independent and flexible adjustment; Independent blanket correction structure; Precise temperature control system, the temperature difference in the range of 5 degrees; Tension adjustment structure, to ensure that the cloth and paper transfer process of tension balance.

用途和特性︰	在卷布上面多色印花，最常見的就是輥筒轉印技術，先將需要轉印的圖案用噴墨打印機打印在具有塗層的昇華轉印紙上面，然後將昇華轉印紙覆蓋在卷布上面一起放入輥筒轉印機的工作臺上，輥筒印花機的主體結構是裝滿導熱油的可以旋轉的輥筒和緊緊壓在輥筒表面的毛毯構成。熱昇華紙和卷布進入輥筒和毛毯之間，在熱和壓力的作用下，熱昇華紙上面的圖案會轉移到卷布表面，這就是市場上廣為流行的熱昇華轉印技術，它具有轉印色彩豐富，印刷效率高，環保，對皮膚損害低等優點，廣氾存在於服裝，鞋帽，床上用品，家居用品，窗帘等家庭用品行業。輥筒印花機的主要參數是輥筒直徑和寬度，它決定了可以轉印的產品效率和寬度，對於輥筒直徑來說，直徑越大，效率越高，目前市場上1500mm的機器已經出現。寬度越大，轉印的布匹的寬度也越大，現在市場上可以做到3500mm寬度的機器。
