SPECIFICATIONS
POLE-POSITION : Momentary Type, SPST with LED
CONTACT RATING : 30V DC,0.1A
CONTACT RESISTANCE : 50mΩ max. 1.5V DC ; 100mA,
                                 by Method of Voltage DROP
INSULATION RESISTANCE : 100MΩ min. 500V DC
DIELECTRIC STRENGTH : Breakdown is not allowable ;
                                500V AC for 1 Minute
OPERATING FORCE : 250±100gf
OPERATING LIFE : 50,000 cycles
OPERATING TEMPERATURE RANGE : -40°C ~ 85°C
TOTAL TRAVEL : 1.2±0.3mm
Materials
CAP : PC
CASE & HOUSING : Nylon 6/6
TERMINALS : Copper alloy with gold plated.
