Auto ATM bank kiosk equipment enclosure

Auto ATM bank kiosk equipment enclosure
Model:-
Brand:Netoptouch
Origin:Made In China
Category:Consumer Electronics & Lighting / Commerce & Finance Electronics / Finance Electronics
Label:ATM kiosk enclosure , ATM banking kiosk , bank equipment kiosk
Price: US $1500 / pc
Min. Order:1 pc

Product Description


Usually you can install it for government service,   Telecommunication service,   Retail, Travel, Transportation, Hotel, University.   It also offers service of inquiry,   data collection and so on.   More information as below. We can design many kiosks according to your requirement.
This kiosk is special kiosk with keyboard designed for our client.   The user could get service and related information by operating this kiosk&touch the kiosk easily.
Overview:
1. Duarable cold rolled steel information kiosk cabinet
2. Powerful Embedded computer
3.19''grade A+ LED monitor
4. operating system, wired internet access
5. Metal keyboard with touch pad
Notes:  Except OS, wired internet access, the above components could be order seperately, you are welcome to order monitor only, or cabinet only. More information, please feel free to contact me.

Parameter:
1) Infrared Touch Panel(SAW&Resistive touch screen available)
a. Infrared Touch screen
b. Resolution: 4096*4096
c. Deviation of Error: ±<1.0%
d. Surface Hardness: Mohs' hardness rating of 7
e. Hitting Life Expectancy: 50,000,000 cycle times
f. Operating Force: Touch force less than 100g(adjust allowed)
g. Response time: less than 8 ms
2) 19''Grade A+ LED monitor
a. Resolution: 1280x1024
b. Brightness: 300cd/m2
c. Contrast ration: 1000: 1
d. Contact Bounce: 5ms
e. Lifelong: more than 50 000 hours
f. Ratio: 4 : 3 or 16 : 9
3) Powerful Computer(update available)
a. CPU: Industrial motherboard with Intel J1900 2.0ghz CPU
b. Storage: 120GB SSD, HDD available.
c. RAM: Kingmax DDRIII4GB(optional)
d. Ports: USB ports, RS-232 ports
RJ 45 interface, 10/100/1000m internet card, usb port
e. Integrate video, Discrete Graphics card, cooling fan, 2 SRS loader speakers
f. Greatwall power supply, support 100v~240v voltage
4) kiosk Frame&enclosure&case&body:
a. Steel frame, 1.2mm~1.5mm cold rolled steel, 2.0mm available.
b. build in power control panel, and hi-fi-speaker.
c. RJ45 interface for internet connect.
The following devices are available:
1.High quality digital Camera, Webcam
2. Bluetooth connection, 3G modem, GPRS, Wifi
3.Control System(cpu / memory / hard disk)
4. Card Reader: RFID card reader, Non touch card reader, IC card reader,   Magnetic card swipe
You are welcome to require to add one of the above devices, or some of the above devices or all of the above device. O ne color~four color available.
Test process:
Before we send the kiosk to you, in order to make sure the kiosk run well after you get it, we will test at least 24 hours for each kiosk.
Warranty
1. 1 year warranty for enclosure.
2. 1 year warranty for electrical parts
3. For mass goods, we will offer some free spare parts of electrical device.
Payment terms:  We accept TT, Western Union, LC(above 30, 000 usd), Escrow. Usually 50% of the total payment as deposit.
N otes:
1. To Saudi Arabia and UAE, CO and SASO is necessary.
2. To Africa countries, there are few ships.
To get more information, warm welcome to cotact us, :).
Price Terms:EXW price
Payment Terms:TT/LC
Packing:foam, carton, wooden case
Lead Time:Usually 15 working days after deposit received
Standards Certificate:CE&FCC&ROHS
