2-in-1 Surge Protector for CCTV System, with 15V DC Operating Voltage
| Model: | DK- DS m 220 ty |
|---|---|
| Brand: | DK |
| Origin: | Made In China |
| Category: | Electronics & Electricity / Breaker & Protector |
| Label: | CCTV surge protector , surge protector , CCTV SPD |
| Price: |
-
|
| Min. Order: | 50 pc |
Product Description
- Characteristics:
- Compliant with CE, RoHS and ISO certifications
- Safe and reasonable price
- Effectively prevent equipment damage such as the instantaneous potential difference between power wire and control lines
- Efficiently discharge lightning current and resist lightning electromagnetic impulse (LEMP) with overload protection devices
- Multi-level surge protection, low residual pressure, fast response, large current capacity and long lifespan
- Small size, convenient installation and easy to maintain
- Specifications:
- Parameters: power wire Video
- Nominal voltage: DC 121V-PP
- Maximum continuous operating voltage: DC 15V
- Nominal operating current: 5A
- Nominal discharge current (8/20μs): 10kA
- Maximum discharge current (8/20μs): 20kA
- Voltage protection level: ≤100V
- Response time: ≤1ns
- Insertion loss: ≤0.5dB
- Parasitic capacitance: ≤50pF
- Impedance: ≤75Ω
- Data transfer rate: 2Mbps
- Protection mode: L1-Pe, L2-Pe L-N-Pe
- Installation mode series
- Interface type: connecting terminals
- Working temperatures: -25 to 70°C
- Working humidity: <95%
- Size: 104 x 63 x 37mm
- Weight: 0.23kg
- Advantages:
- Strictly according to IEC Standard producing
- High speed transmission rate
- Low loss
- Quick respond time and long operation lifespan
- High quality and reasonable price
- High effect R&D and sales groups
- Customized requirements are accepted
