STLB gold Concentrator

STLB gold Concentrator
Model:STLB
Brand:HENGCHENG
Origin:Made In China
Category:Industrial Supplies / Mining Machine
Label:gold concentrator , STLB60 for gold , STLB concentrator
Price: US $39800 / SET
Min. Order:1 SET

Product Description



Description of SF Gold Concentrator

Gold  Concentrator is kind centrifugal concentration equipment. It can be used not only for placer gold mining, but also for hard rock mining to       recover the natural gold, replacing amalgamation. It is also used to recover gold from the old tailings.
Three models are available. Application shows that the recovery can be as high as 99%, especially for the case in recovering the natural gold in lode  ore with 65% of the ore having a milling size of 0. 074mm, the recovery for the natural gold is expected up to 98%.For those natural gold of   0.004mm in particle size, the recovery is 97%.
The cleaning up cycle is 1~4 hours, and the upgrade ratio is up to 1,000 times. The equipment is patented in China.

Technical Specifications



Model

STLB20

STLB30

STLB60

STLB80

STLB100

Feeding Capacity(t/h)

0-0.6

2-3

8-12

35-45(solids)

70-80

Fluidization water Required(m3/h)

2-3

3-5

7-10

30-36

 55-80

Slurry Water Required(m3/h)

1.5-4

5-7

8-12

 35-50

 70-120

Feeding Density(%)

0-50

0-50

0-50

0-50

0-50

Feeding size(mm)

0-3

0-3

0-5

0-5

 0-5

Concentration Cleaning Up Cycle

Vein gold 1-3 Hours Placer gold “2-6 Hours

Concentrate weight(kg)

2

10-20

30-40

60-70

80-90

Feeding size (Kw)

0.75

1.5

4

11

22

Approximate shipping weight(Kg)

145

400

1000

1500

2000

Approximate created shipping Dimensions (mm)

790*785*790

1180*1140*1250

1970*1670*1750

2300*1800*2200

2400*2000*2300



















































STLB gold Concentrator 1STLB gold Concentrator 2STLB gold Concentrator 3STLB gold Concentrator 4STLB gold Concentrator 5
