When the large plate ice machine begins operating normally, the water in the tank below is pumped from the cold water tank to the cold water sprinkler, and then evenly sprinkled on the surface of the evaporator. Through the cycle working of the refrigerant, some water is created into plate ice, while the water which does not become ice returns to the cold water tank below and waits for the next water cycle. After a period of time the water cycle and refrigeration stops and the water and overheating refrigerants gas begin a heat exchange with the plate ice at the same time. The plate ice then loses adhesive force and the ice drops into the ice crushing gadget due to gravity. After the ice is off the water temperature becomes low and it returns into the water sink waiting the next cycle.

Introduction of plate ice: Plate ice is a kind of irregular sheet ice with about 40×40mm~80×80mm in size, and 10 mm~15mm in thickness. The thickness can be adjusted according to ice-making time with the maximum gauge being 25mm. Plate ice is a kind of thick and transparent ice which has good air permeability and a long shelf life.

Application Field: Large plate ice machine has been developed for large-scale ice making applications and it widely used in concrete project, agriculture and fishing industry, fisheries production , aquatic products processing ,aquatic fishing , transportation ice using ,meat product processing , supermarket display, fresh-keeping, food process, medicine, chemical and dye , fermentation engineering, construction project concrete cooling , mine cooling.

Features of big plate ice machine:

- We use aluminum alloy plate as the evaporator, it conforms to the sanitary security requirements.

-Ice dump and water drainage function makes plate ice more clean and transparent.

-It is convenient to install and maintain because of its modular equipment.
- Strong ability to keep cold, super reliability, high efficiency, and supplying stable and reliable low-temperature heat exchange fluid.

- All-automatic control, few operators needed, design of low breakdown rate and small sum of maintenance expense.

-By using heat gas to drop ice and the process only needs 120 seconds.

-Ice making time adopts time control, which can be set to adjust the thickness of the ice.
