Titanium bar

Titanium bar
Model:-
Brand:XINZE
Origin:Made In China
Category:Metallurgy , Mining & Energy / Metallurgy & Mining / Non-ferrous Metal Products
Label:Pure Titanium bar , Titanium alloy bar , Titanium Hex bar
Price: US $85 / KG
Min. Order:100 KG
Inquire Now

Product Description



Specifications

Titanium bar

Material: Gr1,Gr2,6Al4V,etc.
Type: Round
Diameter: 6-200mm,Length:less than 3000mm.
Surface: Polishing

Titanium bar

       Standard: ASM4928,ASTM B348.

       Material:   Gr1,Gr2,6Al-4V,Ti-0.2Pd,Ti-3Al-2.5V,10-2-3,6-2-4-2,etc.

       Type:        Round and square

       Diameter:  6-200mm

       Length:     less than 3000mm

       Melting point:1668 centidegree.

       Boiling point: 2640 centidegree.

Besides , we can produce as per customer's specs. , welcome to contact us for quotation , thanks !

Grade ELEMENT COMPOSITION,%
Ti Al V Fe C N H O Other,Max
Grade 1 Blance _ _ 0.20 0.8 0.03 0.015 0.18 0.40
Grade 2 Blance _ _ 0.30 0.8 0.03 0.015 0.25 0.40
Grade 3 Blance _ _ 0.30 0.8 0.05 0.015 0.35 0.40
Grade 4 Blance _ _ 0.50 0.8 0.05 0.015 0.40 0.40
Grade 5 Blance 5.5-6.75 3.5-4.5 0.40 0.8 0.05 0.015 0.50 0.40
Grade 7 Blance _ _ 0.03 0.8 0.03 0.015 0.25 0.40
Grade 9 Blance _ _ 0.25 0.8 0.03 0.015 0.15 0.40
Grade 12 Blance _ _ 0.30 0.8 0.03 0.015 0.25 0.40



Grade Tensile Strength,min Yield Strength,0.2% Offset Elongation,min %
Ksi Mpa min max
Ksi Mpa Ksi Mpa
Grade 1 35 240 20 138 45 310 24
Grade 2 50 345 40 275 65 450 20
Grade 3 65 450 55 380 80 550 18
Grade 4 80 550 70 483 95 655 15
Grade 5 130 895 120 828 _ _ 10




Titanium bar 1Titanium bar 2Titanium bar 3
