rgb 1x3w hight power LED inground light

Model:	-
Brand:	Comlite
Origin:	Made In China
Category:	Consumer Electronics & Lighting / Lighting / LED Lighting
Label:	rgb inground lights , led inground lights , high power lights
Price:	-
Min. Order:	-

Inquire Now

Product Description

Features:

1.High power LED In-ground light can install in-ground for decoration or illumination. It is widely used for garden, theme park, plaza, etc

2.Single color (pure white, warm white, red, green, blue, yellow) and RGB 3in1 color available

3.12# die-casting aluminum housing . IP67

Specifications:

Housing: 12# die-casting aluminum RAL9007 grey powder coated T=60-80um Adhesion of ISO class 1/ASTM class 4B
Front cover : 316# stainless

Glass:   Tempered glass T=12mm
Lens:   Asymmetrical optical lens, efficiency ≥85%
Loading capacity:   Exert force area of ￠10=1330kgs
Waterproof seal:  Molding shaped double silicone seal
LED:   1 pcs Hight power LEDs
Operating temperature: -20℃-40℃
Power cable:  H05RN-F 2X0.75m㎡ L=0.5m(low voltage)

H05RN-F 4X0.75m㎡ L=0.5m(for RGB)

Mounting sleeve: ABS plastic

Remarks:

1. LED driver is customized when the circumstance of working temperature is below 0℃

2. Use only switching power supply or coiled transformer for 24VDC power input.

3. Customized 316# stainless steel is available.

Technique Parameters:

Part No.	Light Source	Lens Beam Angle(°)	Consumption	Input Voltage(V)	Operating Current(mA)	Typical Luminace
B2BR0102	1X3W	30°	2.6	24VDC	110	Cool white=67 Warm white=57
			3.3	120VAC	48
			3.3	240VAC	28
B2BR0106	1X3W RGB 3in1	30°	R=0.9	24VDC	R=38	R=17
			G=1.3		G=53	G=30
			B=1.3		B=54	B=9
C2BR0102	1X3W	30°	2.6	24VDC	110	Cool white=68.2 Warm white=62.5
			3.3	120VAC	48
			3.3	240VAC	28
C2BR0106	1X3W RGB 3in1	30°	R=0.9	24VDC	R=38	R=18.2
			G=1.3		G=53	G=31.4
			B=1.3		B=54	B=9.3
B2BS0102	1X3W	30°	2.6	24VDC	110	Cool white=67 Warm white=57
			3.3	120VAC	48
			3.3	240VAC	28
B2BS0106	1X3W RGB 3in1	30°	R=0.9	24VDC	R=38	R=17
			G=1.3		G=53	G=30
			B=1.3		B=54	B=9
C2BS0102	1X3W	30°	2.6	24VDC	110	Cool white=68.2 Warm white=62.5
			3.3	120VAC	48
			3.3	240VAC	28
C2BS0106	1X3W RGB 3in1	30°	R=0.9	24VDC	R=38	R=18.2
			G=1.3		G=53	G=31.4
			B=1.3		B=54	B=9.3

Advantage:

1. Beautiful appearance design
2. Long lifespan >50,000 hours
3. Low working voltage, safe for human
4. Green Light, environmental protection
5. Low power consumption, high efficiency, economic
6. Single color, R/G/B and RGB 3 in 1 are available
7. CE and RoHS approval, IP67
