3D modular welding table system

3D modular welding table system
Model:YHD28S2010
Brand:YAHANDA
Origin:Made In China
Category:Industrial Supplies / Machine Hardware / Other Machine Hardware
Label:welding table , welding fixture , 3D welding clamps
Price: -
Min. Order:1 pc

Product Description

Product Name: 3D Modular welding table system

Series: D28 & D16

Technical parameters:
3D modular welding table __ D28 series
1) Hole diameter: 28mm
2) Grid lines: 100mm*100mm
3) Hole pitch: 100mm
4)Material thickness: approx.23.5mm
5)Side surfaces height: 200mm

3D modular welding table __ D16 series
1) Hole diameter: 16mm
2) Grid lines: 50mm*50mm
3) Hole pitch: 50mm
4) Material thickness: approx.14mm
5) Side surfaces height: 100mm

Features & Usages:
The welding table is made of welding steel / cast iron and has 5  precision machined working surfaces. For bearing heavier workpieces, it is reinforced on the underneath side by ribs.
The Modular welding table system is consist of tables and standard  reusable accessories such as clamps, locators, bolts. According to different products, you can configurate different set of welding fixtures for improving production in short time.

Advantages (Comparing with traditional dedicated fixtures):
1) High modularity and flexibility.
    Can be connected and changed arbitrarily according to the shape of      workpiece.
2) High precision.
    The precision can reach decimillimetre(dmm) for fixing and clamping.
3) Quick fixing and clamping.
    Only spending a few minutes to fix and clamp workpieces from one to another.
4) Ease to operate.
    Only 2 hours, any worker can learn how to use it quickly.
5) High price-performance ratio.
    1 set of modular flexible welding fixture can replace all traditional dedicated fixtures. Saved a lot of time, labor, material resources and funds for enterprises.
6) Clean, tidy, little storage space and environmental Friendly.
    Compared with mountains of rusty dedicated fixtures, modular flexible fixtures are the optimal choice.

This system was first used for fixturing prototypes to production or products of little production but with frequently changed design. Now this system is widely used for fixturing weldments as frame structure, vehicle, railway track, construction, electronics etc.

YAHANDA is a professional direct manufacturer for high quality 3D Welding table and Clamping system.
