DSP system 6090 advertising cnc router for acrylic,wood

Model:	KD6090
Brand:	KD
Origin:	Made In China
Category:	Industrial Supplies / Tools / Woodworking
Label:	6090 cnc router , acrylic cnc machine , advertising cutting
Price:	US $3200 / set
Min. Order:	1 set

Product Description

Technical parameter

Model	KD-6090
Power(w)	1.5kw(2.2kw/3kw optional)
Rated power	300~400w
Power source request	AC220v 50Hz
Finishing size(mm)	600×900
Z-travel(mm)	80
Spindle rorating speed	0-40000rmp
Cutting tool diameter	Ø3.175/ Ø 4/ Ø 6
Engine bed resolution	0.025
Mechanical drive	Ball Screws, dust linear guideway
Code form	G code,HPGL
Cooling mode	Water cooling /air cooling
Control system	DSP/NC-studio system
Motor	Servo / stepper motor
Voltage	AC220/50HZ
Software	wentai/type3/Artcam/CAXA

Optional

Application materials

Non-metal materials such as advertising , Plexiglas, glass, bamboo and wood, rubber, marble, granite aluminum,copper and tiles, leather

Application industry

Suitable for woodworking industry and advertising plate, such as copper, iron, aluminum,acrylic,PVC,plexiglass and so on.

Features

1,High- precision gapless ball screws imported from Germany to minimize the gap when the machine is moving.

2,It has 32M saving capacity, which can store many files simultaneously and read at random.

3,Gantry movement, casting table and more durable. It will not distort after long time use. The position precision is much better.

4,It is compatible with Type3, Artcam,Artcut,Wentai,Corel Draw etc

5,Specific saving mode of different points.

warranty

1. 1 year guarantee.

2. 24 hours technical support by e-mail or calling.

3. Use the English Manual and CD Video to know the operating and maintaining.

Payment Terms:	T/T/Western union/paypal

Guangzhou Kedio CNC equipment Co.Ltd
Country/Region:	Guang Dong - China
Business Nature:	Manufacturer
Phone:	13560122503
Contact:	zhou (sales manager)
Last Online:	23 Oct, 2016
