Outer Shell model No :"12W" Outer Shell model No.: 12W
Dimensions：74*29*42MM
Input Voltage: AC100-240V(full r
Input Current (rms): 0.4A
Output Voltage Range: 5V/±5%
Ot tVlt R lti ±5%t t t lt d Output Voltage Regulation: ±5%
Output Current Range: 0.1A-2.5A
Maximum Power (Po): 12.5W
DC Plug Size: 2.5*0.7*8-10mm
DC Cable Length: 1.2/1.5/1.8m (
Protection Fuction: over-current/v
Load Regulation: ±5%
Operating Temperature: 0-40℃
Storage Temperature: -20-75℃
(regular work after two hours in normal temperature) (regular work after two hours in n
Operating Relative Humidity: Ma
MTBF: ±50,000 hours
AC Plug: European Standard (UK
be custom-made)
S f t A d C tifi ti UL CE R HS CB ISO9001 2008 Safety Approved Certification: UL
NSAI, MSDS, etc.
Rippel & Noise: ≤100V
Net Weight:0.093KG
Package: white box or Poly bag
