Features

    1. Latest generation broadcast-grade video processing technology, integrating videowall processor,
        mixed video matrix switcher, multi-picture processor and video synchronous processor
    2. Inputs: analog + digital, SD + HD, totally 28 inputs including CVBS x 7、VGA x 7、DVI / HDMI x 7、
        SDI / HD-SDI x 7
    3. Outputs:16 DVI Full High-Definition digital outputs, each with maximum resolution 1920 x 1080p
    4. Synchronous mosaic technology: synchronous processing of ultra high-definition video played on
        multiple screens or netwrok
    5. Supports zoom mosaic or point-to-point mosaic，single unit can maximally support horizontal 30720 pixels or
        vertical 19200 pixels
    6. 10-picture preview output via one DVI output
    7. 4K2K Ultra high-definition dynamic background picture
    8. Display of four pictures on single display, background picture plus three roaming pictures
    9. Seamless switching and fade-in / fade-out between any two input signals
    10. Multiple pre-saved models, seamless switching and fade-in / fade-out between them
    11. AIAO( Any In Any Out ) function allows for displaying any captured picture in any specific area on screen
    12. Card plug-in and redundant power supply designs bring more flexible and reliable operation
    13. Easy control by panel / RS232 / USB
