Thermal Conductive Double-Sided Tape

BM2000 thermal conductive double-sided tape is composed of acrylic polymer filled with heat conductive ceramic powder and silicone adhesive compound and into, has high thermal conductive and insulating properties, and it is flexible, compressible, adhesion, strong adhesive. Adapt to wide temperature range, can fill the surface irregularities, can be tightly attached heat source device and heat sink, the heat conduction out fast .

Application :

Electronic appliances, LED lighting, hardware industry, printing industry and other manufacturing industry.

Applied to the chip, the flexible circuit board,  and high power transistor and a heat sink or other cooling devices of the adhesion.

Feature :

◆Thermal conductive performance high and stable, its life is longer than the general thermal double-sided stickers, can work under normal temperature (80-120°C) minimum 5 years.

◆Thermal conductive double-sided tape can die cutting products of any shape, and can be posted in advance on a surface so as to used in the future.

◆With good viscidity, can put the heating element and radiator together, as a whole, enhance the cooling effect.

Advantage :

◆High reliability and thermal conductivity

◆Has excellent flexibility, adhesion, self adhesive and high compressibility

◆Can replace the hot melt adhesive, screw, fastener for fixing mode

◆Meet ROHS and UL the environmental requirements

Application and Paste :

Thermal double-sided tape paste on the IC radiator fixed field is the most effective method , professional use in heat sink and chip stick. LED easier to use, paste the thermal double-sided tape between the LED lamp holder and the radiating aluminum plate, with a little force to press ; heat conduction effect is more significant than the general thermal conductive adhesive. This product can also be used in other devices need to heat conduction , replaced by screws, can achieve the most effective heat dissipation .
