Mobile Communication Tower and Antenna Telescopic Mast and High Masts

Model:	-
Brand:	Xuedian
Origin:	-
Category:	Industrial Supplies / Other Industrial Supplies
Label:	telescopic mast , antenna mast , mobile lighting towe
Price:	-
Min. Order:	1 pc

Inquire Now

Product Description

The pneumatic telescopic mast made by our company is characterized by the heavy load, low noise, quick lift, good aseismicity, a good damper for free fall and stability etc. So far the product specs are from 1m 30m.. Our company can custom made the products as per the customers special demand for the retracted height and extended height of mast

The telescopic mast that our company makes adopts the anodized aluminium alloy with high strength, light weight and diverse specifications and we can design and produce according to the need from the customer in order to meet the requirements for height and loading for different field and different occasion. The mast is widely used in military ,lighting equipment , communication ,camera,municipal construction

Specifications
General type	H3-110-1600-4000	H4-110-1900-6000	H5-110-2000-8000	H5-110-2350-10000	H7-150-2600-12000	H7-215-3100-15000	H8-215-3300-18000	H8-270-3500-20000
extended height（m）	4	6	8	10	12	15	18	20
nested height（m）	1.6	1.9	2	2.35	2.6	3.1	3.3	3.5
OD.（mm）	118	118	118	118	160	229	229	284
ID.（mm）	82	66	51	51	51	98	82	118
sections	3	4	5	5	7	7	8	8
Base diameter（mm）	180				250	340		430
loading weight（kg）	100	70	30			100		200
Wind speed limit	When wind speed less than 14m/s,it can be used without guyed line,It can work with guyed line when wind speed is 20m/s.
lift up time	2M/min
swing amount of 8 grade wind（mm）	10	10	15	15	15	18	20	30
nested weight(kg)	14	22	28	39	66	155	260	280
power	220V/50Hz(can be customed to 12v/24v according to customers'requirement)
Ambient temperature	Normal: -45℃~55℃Military :-55℃~80℃
Note:custom size accept
