2inch supermarket kiosk printer with last ticket detection function

Model:	MS-D245D
Brand:	MASUNG
Origin:	Made In China
Category:	Computers & AV Digital / Computer Components / Mouse & Keyboard
Label:	Fiscal printer , inquiry kiosk priner , retail kiosk printer
Price:	¥1 / pc
Min. Order:	1 pc

Inquire Now

Product Description

Features:

Brand name printer mechanism

Reliable auto cutter

Support barcode label printing

Compact panel mounted structure

Ultra high speed

Wide input voltage range

Full/partial cutting (by adjustable)

Rear paper auto loading

Specification:

mechanism：			CAPD245
Printing method			Thermal dot line printing
Dots/line			384 dots/line
Dot pitch			8 dot/mm
Paper width			58 mm
Printing width			48 mm
Paper thickness			54~91 um
Printing speed			150 mm/s
Paper loading			Paper auto loading
Sensors	Head temperature		Thermistor
	Paper press shaft		Mechanical switch
	Paper end		Photo interrupter
Font size			ASCII:917;1224; Chinese: 24*24
Power supply		Logic circuit	2.6~3.6 V
		Motor	4.75 ~9.5 V
Reliability			Circuit: over 1,000,000,000 pulses Cutter: over 7,000,000 cuts Thermal head: over 100 km MCBF: 37,000,000 lines
Ambient environment	Work temperature		-10 ℃~50℃
	Work humidity		20~85% RH
	Storage temperature		-25℃~70℃
	Storage temperature		10~90% RH

Dimension (LWH)	117.85103.593 mm
Weight	Approx 0.45 kg
Interface		RS-232 /USB
power supply		DC 9~24V/2.5A
Command set		ESC/POS
Barcode		supported
Firmware location		2 M NV Flash memory
Buffer		4 KB
SRAM		20 KB
Driver		USB driver
System		Windows/Linux/Android OS
Accessories:		paper near end sensor;
		Paper roll holder
		Paper bezel (paper guide mouth)
		Interface connector
		Power supply unit
		Cable

Applications:

Information kiosk; gas pump station; public payment terminal; ID automation; lottery device; ticket vendor; parking system; queue management machine and more.
