VWG5008 Wind & Solar hybrid charge controller is a smart controller which
adopts the CPU control how to charge to the battery.
With the function of easy operation, high efficiency, low no-load losses, safety,
stability and long life; this controller is a high cost performance product.

Specification:
Model : VWG5008
Battery voltage : 48V
Over discharge voltage : 42±0.2V
Battery over discharge recovery voltage : 47±0.2V
Battery constant voltage : 55±0.2V
Wind turbine rated power : 1.5KW
PV rated power : 0.5KW
Rated power : 2KW

Wind max input current : 35A
PV max input current : 10A
Max discharge current : 30A
No-load loss : ≤80 mA
Recovery time after auto braking : 40min
Efficiency : 95%
Size : 335x 450 x155 mm
Weight : 12.5kg
Cooling method : Natural cooling
