Semi-automatic Bag Packaging Machine

Semi-automatic Bag Packaging Machine
Model:DCS-1B3
Brand:Redstar
Origin:Made In China
Category:Industrial Supplies / Packaging Related Machine
Label:Packaging Machine , Powder Filler , Granule Packger
Price: US $4800 / pc
Min. Order:1 pc
Inquire Now
点击这里给我发消息

Product Description

Introduction:

  • Stainless steel: conforming to the GMP and food health authentication, suitable for packaging the corrosion resistance chemical products.
  • PLC touch screen and man-machine interface: PLC works stably, antijamming, high weighing precision, convenient and easy operation; Weighing feedback proportion track type, overcoming the shortcoming of changes of packaging weight caused by the changes of material proportion.
  • Servo motor-driven: high precision location, strong torque, long life, adjustable rotational speed.
  • Speed reducer: low noise, long life and lifelong maintenance.
  • Packaging weight adjustable at any time, operating condition changeable as necessary, convenient operation
  • Adjustment parameter of each kind of product can be stored for later use but not more than ten.
  • The entire seal air damping glass and stainless steel hopper, clear sound of the material, no dust releasing, with dust exhaust apparatus at the mouth of filling, keeping the workshop clean.
  • Can adapt the ultra fine dust to the big pellet and so on the many kinds of materials by replacing the screw attachment.


Parameter:

           Item Parameter
           Metering mode Screw rotation filling traced by weighing feedback
           Packaging weight 10-5000g(screw attachment changeable)
           Weighing range 1-6000g(Resolution 1g)
           Packaging precision:
           Packaging weight ≤100g with an error ≤±0.5-1g
           Packaging weight 100-1000g with an error ≤±0.5%-1%
           Packaging weight >1000g with an error ≤±0.25%-0.5%
           Packaging rate 10-50bags/min
           Power supply Three-phase 380V(or single phase 220V)50-60Hz
           Total power 1.8KW
           Weight 260kg
           Dimensions 800×1200×2050mm
           Hopper volume 50L



Our Services:
XUNJIE has a highly sophisticated technical talent, has a high- quality team, can in a timely manner to provide customers with comprehensive after-sale service.No damage to human factors, all products one year warranty, life-long maintenance. Professional production, quality assurance, affordable, welcome to inquire, all factory direct sales, look forward to building cooperate with you wholeheartedly!

If you have any questions,please don't hesitate to contact us.  We will reply to you asap. Thank you and welcome to XUNJIE.
