EPS Block Cutting Machine (Basic)

EPS Block Cutting Machine (Basic)
Model:SPC200-800A Blo
Brand:Shengchin
Origin:Made In China
Category:Construction & Decoration / Shaped Building Material
Label:EPS Block Cutting Ma
Price: -
Min. Order:10 pc
Inquire Now

Product Description

EPS Block Cutting Machine (Basic) is one of the most representative and competitive advantages of our EPS Making Machines, With the world's most advanced production technology and equipments and a principle of "High quality, high efficiency", EPS Block Cutting Machine (Basic) will always be highly praised by domestic and foreign customers, our company commitment, we provide you with the EPS Block Cutting Machine (Basic) service is higher than the EPS Block Cutting Machine (Basic) itself.

MAIN FEATURES
1.The main frame of the machine is welded from square profile steel, with strong structure, high strength and no deformation;
2.The machine can make both thickness and length cutting on the same machine, the width cutting will be done by manual operation;
3.The machine adopts converter speed governing advantageous in stable moving, large range(0-4m/min)of step-less speed governing, suitable for requirements of low-speed cutting and fast cutter-retract;
4.Voltage adjustment:Adopts 10KVA multi-tapped special transformer for adjustment with wide adjustable range and multiple voltages;


SPC200-800A Block Cutting Line

Item SPC200A SPC400A SPC600A SPC800A
Max Block Size 2000*1300
*1300(mm)
4000*1300
*1300(mm)
6000*1300
*1300(mm)
8000*1300
*1300(mm)
Connected Load 11.2KW 11.2KW 11.2KW 11.2KW
Overall Dimension 4800*1950
*1850mm
6800*1950
*2450mm
8800*1950
*2450mm
10800*1950
*2450mm
Overall Weight 800kg 1200kg 1600kg 2000kg
Vote: We custom make machine according to customer request
