Automatic bag in box BIB stand up pouch with gland bag making machine
| Model: | JDM650-BIB |
|---|---|
| Brand: | JUDING |
| Origin: | Made In China |
| Category: | Industrial Supplies / Packaging Related Machine |
| Label: | bag in box bag , BIB bagmakingmachine , bag-in-box |
| Price: |
¥1000000
/ set
|
| Min. Order: | 1 set |
Product Description
Automatic Bag-In-Box Making Machine
Tap press online automatic, wine tap press on same direction
The machine is used to make packing bags with plastic spouts, the bag making and
the spout sealing are done at the same time. The products are widely used for high-capacity
packaging of food, such as fruit juice, chocolate plasma, red wine soy sauce etc
Main Technique Features
•PLC control, parameter set through interface, high anti-interference ability and easy operation
•Double film unwinding frames design, multi-layer film drive at same time, finish bag-making once
•Main motor servo drive, adjustable hot-sealing time and hot sealing rate
•Film unwinding, film feed, hole punching, spout sealing, bag making are all fulfilled automatically
•Detector photo-cell for checking film feed and spout sealing. Automatic alarm and stop
MAIN Technical Parameter:
| Model | JDM650-BIB |
| Film Size | Max.1300mm*800 |
| Bag Size | Max.700mm*650mm |
| Capacity | 25-30 pieces/min |
| Mouth Spe. | According to client provide |
| Total Power | 50.5KW |
| Power | AC 380V,50HZ,3P |
| Compressed air | 0.5-0.7Mpa 100NL/min |
| Dimension | L*W*H 15200*4200*1900mm |
| Weight | 8000Kg |
| Payment Terms: | T/T, L/C, DP |
|---|---|
