Model:

PPBW-24/ PPBW-32

Specification:

It can weld pipe with pipe, pipe with conical pipe, pipe with flange, elbows and tees automatically for root pass, filling in and cap pass with TIG, GMAW and SAW welding procedure.

According to welding pipe materials and procedure requirements, you can choose one or more from the following welding procedures: TIG, GMAW, TIG+GMAW, TIG+SAW, GMAW+SAW and TIG+GMAW+SAW.

Workpiece type：

Performance features:

Pipe diameter applicable for PPBW-24:Φ60-630mm, Pipe diameter applicable for PPBW-32:Φ60-830mm.

or made according to customers’ requirements.

Pipe wall thickness applicable: 2-30mm

Bevel type applicable: V, U, double V, etc.

Materials applicable: carbon steel, stainless steel, alloy steel and cryogenic steel, etc.

Welding thickness: 3mm/time

Welding capacity: TIG: 80-120inch/day/welding head, MIG: 250-300inch/day/welding head.

Welding guns quantity: 1pc or 2pcs (according to welding procedure)

Welding gun angel: Adjustable

Welding oscillator: NCL oscillator

Gun clamping mechanism: aluminum alloy gun clamping mechanism

Control system: PLC control

Operator interface: human-computer interface

Welding wire diameter: Φ1.2mm

Protective gas: TIG: argon, MIG: mixed gas (80%argon and 20% CO2)

More than 98% qualified x-ray test, first ultrasonic text or second weld pass rate
