Product information：
FUNTION
Applies to: Width 38-170mm, Height 70-330 (mm) (specific to the buyer provide drawings), automatic 4 sides frame brush plate border.
1、Main features: all movements are driven by one main motor; all functions are mechanical device, without the compressed air, without PLC program control, simple use and of high reliability.
2、The equipment adopts manual assembly plate, synchronous and continuous conveying plate at the same time the brush automatic brush light work, every movement is stable and reliable.
3、The machine has the advantages of simple structure, convenient adjustment and brush replacement, adjustment of the little parts, convenient replacement model.
4、Environmental protection part of the whole and local seal, PVC central dust collection, meet the
requirements of environmental protection

THE DEVICE BASICALLY COMPOSED
1、Collection system equipment configuration controller, main body, transmission mechanism, brushing component, the material collecting device, waste collect system.
2、Equipment configure quantity
（1）Electric controller：1
（2）Main system：1
（3）Transmission mechanism：1
（4）Brush assembly：3
（5）Dust port：4
3、Device configuration
(1）Control cabinet: PLC, text display, solid state relays.
（2） Main body: frame, steel, steel plate.
（3）Transmission mechanism: Synchronous belt
（4）Brush: brush wheel motor, optical components, a position adjusting mechanism.
（5）Waste collection system: Waste guiding device, dust collection container, dust exhaust port.
（6）Working procedure: artificial feeding→ top side brush→both sides brush→ bottom side brush
→ artificial discharging into the boxEQUIPMENT SPECIFICATIONS INDEX REQUIREMENTS
1.Equipment Specifications Model: APBM-##03 (See the fellow list)
2.Brush plate size: Width 52-88mm（Belt width 50mm) H:70-150mm,(specifically plate should provide
the buyer drawings first)
3.Production speed: ≥ 300 pieces/min
4.The rejection rate:≤ 1. 0%, the premise of the buyer to provide the plates of the deformation
is not greater than 0.5mm.
5.Brush wheel: φ128Xφ16X10mm
6.External pumping dust interface size: φ148mm.
7. Brush motor specifications: gear motor power 0.75KW.
8.Power supply: Three phase AC380V±10% 50Hz
9. Total weight: 1.0 T
10. Equipment Dimensions (L x W x H mm): 2780*800*1800
11. Device color: gray and black.
12. Working hours: 24 hours continuous work properly.
