Automatic Continuous PU Foaming Machine

Model:	KX-1800
Brand:	KEXUAN
Origin:	Made In China
Category:	Industrial Supplies / Rubber & Plastics Machine
Label:	Auto Foaming Machine , Foam Production Line , Foaming Machine
Price:	¥650000 / SET
Min. Order:	1 SET

Inquire Now

Product Description

Fully-Automatic Continuous Foaming Machine

Model: KX-100

Mainly Usage
Fully-Automatic Continuous Foaming Machine is used in soft PU products. Foaming Density Range:8-70kg/CBM.The ideal Foam products are involved with Furniture, Shoes, Bra and Electricals field, also suitable for Mattresses, Sofa, Package, Cloths and Car industry. User can save over two hundred different of recipes, To adjust and change them by user at any time.User can remote control it by internet that reduce production cost scientific and directly.PLC Digital Touch Screen or Electric Control System. ----This machine can change the formulation no need stop machine , no need test flow, The degree of resistance to yellow can reach 3~5 international standard, cooperatethe customer’s request to offer diffrend formulation, and trainng the foaming engineer.

Specifications:

Max.Output Capacity:	200～350kg/min(Continuous Type)
Mixer Total Power:	37kw
Max.Mixing Speed:	2500～6000r/min
Foaming Type:	Trough & Sprayer
Save Formular Q.T.Y.:	13 Groups.
Foaming Size:	W2300mm*H1200mm(Width Adjustable)
Control System:	PLC Digital Touch Screen(Made In TaiWan) And Electirc Control System.
PPG Tank:	5Ton*1Set.
POP Tank:	5Ton*1Set.
PPG+CACO3 Tank	5Ton*1Set
Fire-Retardard Tank	1Ton*1Set
TDI Tank:	4Ton*1Set.
MC Tank:	1 Ton*1Set.
Silicone +Water Tanks:	180L*2Sets
T-9+Amine+Color (A.B.C):	180L*5Sets
Side Wall Size:	L18m*H1200mm
Fallplate:	L7m*W1.35～2.4m(Adjustable)
Foaming Platform:	L2900mmW3000mmH700mm
Conveyor Line:	L18m
Side/Bottom Paper Feed & Rewind System:	2Sets.
Walkway:	W500mm*L18m
Air Valves	Euro Standard
Chiller(Both Cooling & Heating System):	1Set*1.5HP(Made In TaiWan)
Side Film Lifting System:	1Set.
Foaming Density Range:	8～70kg/Cubicmeter.
Match With Block Cutter:	1Set.
Total Motor Power:	Approx 125kw.
Air Compressor:	Match With (11HP)*1Set
Machine N.W.:	Approx 25Ton
Floor Space Required:	L45mW5mH4.5m.
