1.Application
Apply to the hard and soft copper ot aluminium stranded, KVV,RVV or cabled telephone wire of more than 4 pairs core wire.
2.Specification
| Machine type |
JJ-1000 |
JJ-1250 |
| Finish stranding wire/(mm) |
MAX Φ8.0 |
MAX Φ15.0 |
| Stranding sec.area(mm²) |
MAX 1.2-38.0 |
MAX 3.5-50 |
| Insulated wire individua(mm) |
MAX 1.0-2.5 |
MAX 1.0-3.5 |
| Max. RPM |
800RPM(1600t/min) |
600RPM(1200t/min) |
| Main motor |
40HP DC Motor |
50HP DC Motor |
| Cintrol system |
Parameder controlled by touch an LCD |
| Bobbin model |
Motor-driven, fixed position |
| Net weight |
9500kg |
11000kg |
3. Machine main electric brand
Motor: Siemens (china) Motor
Transducer: American Emerson transducer
Temperature controller: Omron Brand PID Smart type
Man-Machine interface: 10.2 inch color
PLC and Control Module: Siemens
Screw and Barrel: Produced by jinhu Company.
Bearing: Japan NSK or other same quality brand
Low voltage electrical parts: Adopts SIEMENS, OMRON, SCHNEIDER brands,etc.
