NEW 1220CC DIESEL 4WD UTV/UTILITY VEHICLE

NEW 1220CC DIESEL 4WD UTV/UTILITY VEHICLE
Model:EP1200UV
Brand:EPEAX
Origin:Made In China
Category:Transportation / Vehicles / Special Transportation Equipment
Label:UTV , DIESEL UTV , 4WD DIESEL UTV
Price: -
Min. Order:1 pc

Product Description

Vehicle model : Cubs 1200UV

Standard

Optional

Specifications

Overall dimensions

2980 x 1534 x 1920mm

\

Cargo / Dump bed

1100 x 1534 x 270mm

\

Wheel base

1920mm

\

Wheel track

1220mm

\

Min. ground clearance

300mm

\

Weight Data

Persons in cab

2 persons

\

Curb weight

730Kg

\

Payload

550Kg

\

Gross vehicle weight

1280Kg

\

Performance

Driving model

4 x 4 / 2 differential lock, manual switch

\

Max. speed

55Km/h

\

Max. slope of climb

60%

\

Min. turning radius

4.6m at 30km/h

\

Fuel consumption

7 liters

\

Power system

Engine model

3M78 High pressure common rail diesel engine

\

Engine type

3 cylinder 4 stroke water cooling

\

Rated. power

18.5Kw per 3200rpm

\

Max. torque

71.8N.m per 2100rpm

\

Displacement

1220cc

\

Basic equipment

Transmission model

CVT  L/H//N/R

Front windshield

Front suspension

Independent Dual A Arm

Rear windshield

Rear suspension

Independent Dual A Arm

Half doors

Steering gear type

Rack and pinion steering gear, EPS

Winch 3000lbs

Service brake

Hydraulic dual circuits, front/rear disc

Winch 3500lbs

Parking brake

Rear wheel edge brake

Enclosed doors

Wheels and tyre

Front 26*9-14, Rear 26*11-14

Wiper and Roof

Fuel tank capacity

30 liters

LED top light bar

Lights & Signals

LED(turningpositionbrakinglighting)

Dump bed

Ventilation

\

Heater

Multimedia

\

FM with MP3

Payment Terms:TT/LC
Packing:IRON BRACKET WITH CARTON
Lead Time:IN 30 DAYS AFTER PAYMENT
Standards Certificate:CE
