Oilless Guide Bushing Guide Plate in Bronze and Graphite

Model:	-
Brand:	Jouder
Origin:	Made In China
Category:	Industrial Supplies / Machine Hardware / Mold
Label:	Guide bushing , guide plates , bronze and graphite
Price:	-
Min. Order:	1 pc

Inquire Now

Product Description

1, Provide most kinds of components, both standards and custom.
2, Make according to drawing even real sample.
3, 100% inspected before shipping
4, Each piece guaranteed as request.
5. The more you order, the better the price is.
6. 1 pcs is acceptable.

Drawing NO.	Material	φd1	φd2	φd3	φd4	L1	L3	L4	L5	r	Halte-stuck
Drawing NO.	Material	H7	h6	-0.3	-0.8	0.5	±0.1	±1	-0.5		Halte-stuck
5316	Bronze+graphite	24/25	32	32	40	40	6.3	3	10	3
		30/32	40	40	50	50		4	12
		38/40	50	50	63	63		5	15
		50	63	63	71	71		6.3	17	5
		60/63	80	80	90	90	10	8	19	6
		80	100	100	112	112		10	22	8
		100	125	125	140	140		12.5	21	10
		125	160	160	180	180		16	30	12
		160	200	200	220	220		16	32	18


Drawing NO.	Material	b	L	h	b1	b2	h1	h2	φd1	φd2	Bestell-nummer
Drawing NO.	Material	h9	0/-0.4	h11	b1	+0.3/0	+0.2/0	0/-0.3	+0.2/0	+0.2/0	Bestell-nummer
5301	S45C	20	20	10	7.5	5	7	6.3	7	11	5301.06
		25	20	12	10	5	8.5	6.3	9	15	5301.08
		32	32	16	11	10	11.5	10	11.5	17.5	5301.10
