1:Product Name:Adjustable Jack Post Shoring Prop for Construction

Introduction of Shoring Props

Shoring Props is widely used in vertical structural support, which can be adapted to any vertical support of floor and module shape.

It is support member with simple and flexible operation, good stability and easy installation.

Advantage:

1) Simple and flexible operation, quick disassemble.

2) High capacity and Safety.

3) Surface treatment with Hot dip galvanized or hot dipping paint after galvanization, the treatment ensure the product anti-corrosive that prolong the useful time and enhance the cycle use. It is widely used in various construction projects.

2:Specification:

1)

Item No.	Adjustable	Main Pipe	Wight	Main Pipe	Weight	Main Pipe	Weight
JSSPA-160-290	1.6-2.9m	Ф48x3.0mm Ф60x2.75mm	13.5kg	Ф48x3.5mm Ф60x3.0mm	14.8kg	Ф48x4.0mm Ф60x3.5mm	16.5kg
JSSPA-180-320	1.8-3.2m		14.6kg		16.0kg		17.8kg
JSSPA-200-360	2.0-3.6m		16.0kg		17.6kg		19.6kg
JSSPA-220-400	2.2-4.0m		17.4kg		19.2kg		21.5kg



2)

Item No.	Adjustable	Main Pipe	Wight	Main Pipe	Weight	Main Pipe	Weight
JSSPB-160-290	1.6-2.9m	Ф40x1.8mm Ф48x1.6mm	7.25kg	Ф40x2.0mm Ф48x1.6mm	7.9kg	Ф40x2.2mm Ф48x2.0mm	8.4kg
JSSPB-180-320	1.8-3.2m		7.77kg		8.43kg		9.1kg
JSSPB-200-360	2.0-3.6m		8.47kg		9.22kg		9.95kg
JSSPB-220-400	2.2-4.0m		9.18kg		10.0kg		10.82kg



3)Scaffolding adjustable steel painted shoring prop Compared with other formwork shoring systems, shoring props are the most economical, convenient & quickest way in construction, wide range of application. Wide flexible design & production, shoring props can be customized in different...

Item No.	Adjustable	Main Pipe	Weight
JSSPD-240-390	2.4-3.9m	Ф48x2.0 Ф60x1.8	12kg



Item No.	Adjustable	Main Pipe	Weight	Main Pipe	Weight	Main Pipe	Weight
JSSPE-252-390	2.52-3.9m	Ф48x1.6Ф60x1.5	9.5kg	Ф48x1.7Ф60x1.6	10kg	Ф48x2.0Ф60x1.8	11.2kg



Item No.	Adjustable	Main Pipe	Weight
JSSPE-220-400	2.24.0m	Ф48x1.8 Ф60x1.6	10.6kg



Item No.	Adjustable	Main Pipe	Wight	Main Pipe	Weight	Main Pipe	Weight
JSSPC-160-290	1.6-2.9m	Ф60X3.0mm Ф76x2.75mm	18.1kg	Ф60X3.5mm Ф76x3.0mm	19.8kg	Ф60X4.0mm Ф76x3.5mm	--kg
JSSPC-180-320	1.8-3.2m		19.5kg		21.4kg		--kg
JSSPC-200-360	2.0-3.6m		21.41kg		23.5kg		26.2kg
JSSPC-220-400	2.2-4.0m		23.3kg		25.6kg		28.7kg
JSSPC-270-500	2.7-5.0		27.9kg		30.8kg		34.7kg



3:Packaging:Bundles;Steel Pallet or According to Customer Request

4:The company information:

Our factory Founded in the year 1997,since year 2010 as a manufacturer of scaffolding and formwork in China.We are located in Nanjing city,centred around Shanghai in the Yangtze delta economic circle.We have facilities covering a total area of 23000 square meters,our employees reach up to 80 staffs,including 5 people of management team,3 engineers,6 quality control(QC),advanced testing laboratory and workers,our annual production reach 5 million lbs of products.

By the principle of “Technology Innovation”,we are dedicated to design and produce all kinds of scaffolding products.Our main products include:Ringlock scaffolding system,Cuplock scaffolding system,Kwikstage scaffolding system,Haki scaffolding system,Frame scaffolding system and Steel prop system,which is widely used in major residential,commercial and industrial projects at home and abroad.

We are committed to designing optimal program,high quality products and outstanding service after sales based on satisfaction from customers,considering from the customers’ perspective,we strive to create more value for them.

For further information about our scaffold,please contact us by e-mail or call,you will be glad you did.
