Pad printer with pad-clean device P1-408CPP

Model:	P1-408CPP
Brand:	KC
Origin:	Made In China
Category:	Industrial Supplies / Plate Making & Printing Machine
Label:	pad printer , pad printing machine , pad press
Price:	US $2936 / pic
Min. Order:	1 pic

Inquire Now

Product Description

Steel plate sliding type monochrome ink cup pad printer
Includes printing plate device, ink cup system, ink scraper, rubber head device, etc.
In terms of performance, it completes the printing action by sliding the steel plate, and the ink cup can better control the amount of ink, so that the ink is evenly distributed.
It has a wide range of applications. In terms of stationery, it can be used for printing pen holders, etc.; in the toy industry, it can be used for printing surface patterns of plastic toys; it can also be used for printing the shells of small electronic products, such as calculators, electronic dictionaries, etc., and printing logos and simple patterns on the shells.

Advantages

• High printing quality: through steel plate sliding and ink cup ink supply, the ink is evenly distributed, the printed pattern is clear, the text is sharp, the color reproduction is high, and the pattern is not easy to deform.

• Good ink control: the sealing structure of the oil cup reduces ink volatilization and waste, saves costs, and the ink concentration is stable after long-term placement, which can reduce the number of ink adjustments and improve production efficiency.

One color pad printer with automatically pad-clean device //Structure
Working table	Standard working table with 3-size adjustment
Ink supply system	Closed -type system
Pad treatment	Automatic rubber pad chean device
Plate type	10mm Thick steel plate.
Pad dropping control	Simple-cylinder , simultaneously pressing
One color pad printer//Usage and characters
Guide	Installing pad clean device to increase the pad printing quality; With sealed cup to protect environment ， VOC volatilization reduced 86% and save ink over 25%. With coin aluminum structure ensure more stabilization and long life. Independent cylinder to drive sealed cup ensure removing ink completely. Make min Pressure to remove ink and prolong the life of sealed cup and steel plate; Both thick steel plates and thin steel plates installed , Choose according to customer requirements. Can print almost small size objects . So sold very nice in the world. Widely used in the industry field of cosmetics case, electron parts, Toys, plastics production, Housewares, gifts, decorations. Completely printing solution including ink and thinner , fixtures, steel plates, rubber pads provided when you send us samples;
Application fields	Electrons, hardware, autos, toys, gifts, Plastics, household appliances, artwork, stationery, adornment, cosmetic, commodity, sport goods, decorative lightings, woodwork, office supplies, Photo Materials, Kitchen utensils, Hotel supplies, Computer, Mobile, etc., industrial field.
One color pad printer //Parameter
Technical parameters	P1-408CPP
	Max. steel plate: 100 ×200mm； Ink cup size: Ф90mm； Max. printing area :80×80 mm ； Printable color quantity:1； Max. printing speed: 1300 pcs/h。
	P1-410CPP	P1-412CPP
	Max. plate size: 100×250mm; Ink cup diameter: Ф90mm; Max. printing area: 80×130mm; Max. printing speed: 1100pcs/h; Printable color quantity:1	Max. plate size: 100×300mm; Ink cup diameter: Ф90mm; Max. printing area: 80×170mm; Max. printing speed: 1000pcs/h; Printable color quantity:1
Works supply	110V-220VPower supply； 5-7Bar Compress air；
Package list	Package size:0.970×0.900×1.480m; Gross weight: 126KG; CBM: 1.2921
H.S.Code	8443198000
Certificate	CE
One color pad printer //Advantage
Function	Automatically pad clean device for more high printing quality; Using the dimensional modulating table, can be up and down, front, left, and rotation of the adjustment, which will help precise printing; T-slot structure, easy installation of fixtures and products; Hand pick and place workpiece, operating more handy; PLC program control, the movement is more accurate and reliable; Test machine can be a single action adjustment, adjustment is completed, you can use the automatic mode of operation; Equipped with four counters, can effectively measure the number of products; Structure using die-casting aluminum, lightweight and solid. Independent Rubber pad up and down stroke and speed adjustment function; Sealed cup ink system, ink savings, and also to prevent the ink in the VOC emission into the air pollution of the environment, health protection of operating personnel; Either use the tungsten steel ring, you can use a ceramic ring, and easy to replace; Temporary shutdown can prevent the ink to dry within the Sealed cup with INK function; World famous pneumatic components to ensure the long service life of machine; Rubber sliding shaft with hardened guide shaft grinding of high hardness, good abrasion resistance.

Accessories:	Pad printers target a wide variety of products, with differences in shape and material. Different products have different printing positions and printing effects. Printing engineers must design different printing processes and select different printing consumables according to user needs. 1) Pad printing plates: The plates are made of thick steel plates, thin steel sheets, resin plates, etc. They are used on oil cup pad printers or open pad printers. The printed pattern needs to be etched on the plates. Generally, a single-color pad printer is equipped with one plate, a two-color pad printer is equipped with two plates, and so on. 2) Fixture: The printed product must be fixed on the workbench with a fixture to ensure that the printing position meets the requirements. The fixture can be made of metal or non-metal materials. A single-color pad printer and a shuttle pad printer require a fixture, while a turntable pad printer needs to be equipped with a number of fixtures equal to the number of workstations. 3) Ink: The ink type is selected according to the material of the product, and the ink color is selected according to the printed pattern. Different types of inks should match different pad printing processes. After the ink dries, it should be able to firmly adhere to the product surface. A single-color pad printer uses one color of ink at a time, a four-color pad printer uses four colors of ink, and so on. 4) Pad printing rubber head: Different product shapes and different pad printing patterns require pad printing rubber heads of different shapes. The pad printing rubber head should be able to perfectly achieve the pad printing task and maintain the stability of the properties. 5) Blade or oil cup: Blades are used on open pad printing machines, and oil cups are used on closed pad printing machines. Blades and oil cups should be able to scrape off the ink on the steel plate and should be replaced in time when damaged.

Accessories:

Pad printers target a wide variety of products, with differences in shape and material. Different products have different printing positions and printing effects. Printing engineers must design different printing processes and select different printing consumables according to user needs.
1) Pad printing plates: The plates are made of thick steel plates, thin steel sheets, resin plates, etc. They are used on oil cup pad printers or open pad printers. The printed pattern needs to be etched on the plates. Generally, a single-color pad printer is equipped with one plate, a two-color pad printer is equipped with two plates, and so on.
2) Fixture: The printed product must be fixed on the workbench with a fixture to ensure that the printing position meets the requirements. The fixture can be made of metal or non-metal materials. A single-color pad printer and a shuttle pad printer require a fixture, while a turntable pad printer needs to be equipped with a number of fixtures equal to the number of workstations.
3) Ink: The ink type is selected according to the material of the product, and the ink color is selected according to the printed pattern. Different types of inks should match different pad printing processes. After the ink dries, it should be able to firmly adhere to the product surface. A single-color pad printer uses one color of ink at a time, a four-color pad printer uses four colors of ink, and so on.
4) Pad printing rubber head: Different product shapes and different pad printing patterns require pad printing rubber heads of different shapes. The pad printing rubber head should be able to perfectly achieve the pad printing task and maintain the stability of the properties.
5) Blade or oil cup: Blades are used on open pad printing machines, and oil cups are used on closed pad printing machines. Blades and oil cups should be able to scrape off the ink on the steel plate and should be replaced in time when damaged.
