Machine parameters: Printing workpiece shape, plane, printing table size (mm)200 * 200 screen frame size (mm)450 * 450 printing area (mm)180 * 150 running speed (PCS/HR)1000 Cycle/hour, standard parts thickness (mm)0.1-1 power supply power (V/HZ/W)220V/50HZ/1750W air pressure requirement (kg)5-7 machine weight (kg)500 body size (mm)800 * 1100 * 1800 equipment main configuration: 1. Front and rear running table design, running table using servo linear motor, positioning, positioning accuracy. 2. The counterpoint platform adopts XXY structure, and the counterpoint precision is high. 3,1.3 million high-resolution imported industrial cameras, according to customer requirements for more than a few. 4, the horizontal slide seat uses the linear guide rail structure, the intensity and the precision raise, the lightsome steady. 5, screen lifting using servo motor with ball screw drive, linear guide, fast transport speed, small voice. Numerical control, many procedures can be switched, easy to operate
