CEL-S500-T5 simulated daylight xenon lamp light source, using the xenon lamp power supply developed by CEL Jinyuan, the light output stability increased significantly, < ± 0.5%, which is conducive to solar cells, photoelectric chemical PEC, photothermal seawater evaporation and other research areas with high requirements for stability.

CEL-S500-T5 simulated daylight xenon lamp light source The structural design used, the wind and light path design is more reasonable, optimizing the heat dissipation effect; increased temperature monitoring to protect the lamp and system safety; power-off delay function, increasing the service life of the lamp; light source can be installed inside the 150W, 350W, 500W high-pressure short-arc spherical xenon lamp, the formation of arc light discharge under high-frequency, high-pressure excitation. High-pressure short-arc spherical xenon lamp is a point light source with a very small luminous point, which radiates a strong and stable continuous spectrum of ultraviolet, visible and near-infrared light when ignited. Photocatalysis, seawater evaporation and other fields.

Advantageous features: high-quality optical lens to improve light collection efficiency; the use of back light reflector structure to improve light collection efficiency; built-in three-dimensional adjustment platform, optical precision adjustment can be achieved; a full range of accessories, fiber optic connections and a variety of filters; color temperature up to 6000K, simulating sunlight; cooling mode using fan air-cooled cycle cooling.
