Overview

Quick Details

Place of Origin:     Guangdong, China

Brand Name:   Kongshi

Application:    Jewelry design/dental model/3D printing model

Features:    High Resolution 3D Printer

Production Capacity:  10000pcs/Month

Warranty:     1 Year

Dimension(L*W*H):     620*450*420mm

Voltage:     AC220(110-240 50/60Hz) DC24V(Built in power)

Applicable Industries:    Home Use, Retail, Printing Shops, : jewelry casting, art design, Cartoon Models

Showroom Location:    None

Usage:    jewelry casting dental model 3d printing

Weight:    18 KG

Automatic Grade： Automatic

Color & Page:    single color

Year:    2021

Condition:   New

Plate Type:    3D printer

Molding Technology:   LCD

Forming size:    192*120*270MM(8.9inch)

Key Selling Points:   High-accuracy

Marketing Type:    New Product 2020

Machinery Test Report:   Provided

Video outgoing-inspection:    Provided

Warranty of core components:    1 Year

Core Components:   Motor, PLC

Z transmission:   0.7N big torque motor

Motor:    42 Motor

screen:   8.9inch

Resolution:   3840*2400

Display:   3.5 inch touch screen

Connection method:   USB

light source:    UV LED100W(405mm) Taiwan Epileds chip

The intensity of UV:   30W/m2

Bottom time:   30-50S

Exposure time:    1-10S

After-sales Service Provided:   Online support, Video technical support

After Warranty Service:   Video technical support, Online support

Local Service Location:   None

Certification:   CE,Rohs,SGS

Supply Ability：

Supply Ability   1000 Set/Sets per Month



Packaging & Delivery

Packaging Details ：  Carton

                      Port  ：  YANTIAN SHENZHEN



Quantity(Sets)	1 - 100	>100
Est. Time(days)	15	To be negotiated





Product Description

KS-A114K parameters

Body:	All aluminum alloy structure	FEP membrane:	0.15(jampan Daikin)
Z transmission:	0.7N big torque motor	Print size:	192*120*270MM(8.9inch)
Motor:	42 Motor	Bottom time:	30-50S
guide:	Double rail + T-shaped screw	Exposure time:	1-10S
screen:	8.9inch	Print layer thickness:	0.1/0.05/0.025/0.01mm
Resolution:	3840*2400	Z axis positioning accuracy:	0.01mm
Voltage:	AC220(110-240 50/60Hz) DC24V(Built in power)	X Y point distance:	0.05mm
Display:	3.5 inch touch screen	Z-axis accuracy:	0.025mm
Connection method:	USB	Number of packages:	1PCS
light source:	UV LED100W(405mm) Taiwan Epileds chip	weight:	18KG
The intensity of UV:	30W/m2	Outer packing dimensions	620*450*420mm
power:	100W	system:	ChiTuBox64
		Leveling:	Automatic leveling
