3V Gas Cooker Controller with Solenoid Valve Function description

The two poles can ignite separately or simultaneously. If they ignite simutaneously, they will ignite alternately every 1S.

If the flame is out in ignition time, it can ignite again.

 It is with alarm function.

The working signal synchronizes with valve holding signal.

Main technical parameter

Test item

Standard

Note

Rated operating voltage

3V

Operating voltage range

2-3.3VDC

Ignition frequency

8-15Hz

3V

≥4Hz

2.1V

Ignition distance

≥5mm

Ignition current

≤120mA

Valve open current

≥450mA

Valve  holding voltage

≥2.8V

Ignition time

8±1s

3V

Igniiton No.

1 time

Valve keep open time after ignition

0.2±0.1s

Valve open time

0.5±0.1s

Flame detection sensibility

1N4007+15M

Ignition energy

≥1mJ

Ignition cycle

≤400ms

Output hi-voltage

≥12KV

with 30pF loading

Ignition pulse width

≥12us

Operating current

≤150mA

Operating ambient humdity

＜95%

Operating ambient temperature

-10～70℃

Storage temperature

-20～75℃

Life cycle

ABS antiflaming>100,000 cycles
